Yamaha URX44V B 6x4 Dual USB-C Audio & HDMI Video Interface with 32-bit / 192kHz Support & Touchscreen - Black Finish

ITEM #: YMH-URX44V-B MFG #: URX44V-B

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$950.00

Our Price:

$799.99

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


URX44V-B - Overview

Your Vision Come To Life

The Yamaha URX44V is a 6-in/4-out USB-C audio interface designed for creators who demand professional audio and seamless video integration. It supports 32-bit/192kHz sound quality and combines DSP-powered mixing and effects with a touch LCD and physical controller. An HDMI-USB capture function allows high-definition video and audio from cameras, consoles, or other devices, making it ideal for live streaming, podcast production, game streaming, or small video projects. With professional audio quality, versatile I/O, and video capability, the URX44V offers an all-in-one solution that ensures productions both look and sound exceptional.

URX is an ideal audio interface for creators upgrading from entry-level-high quality, versatile, and intuitive and fast (easy to use).

Level Up
You know the fundamentals, you've put in the hours, and your audio production game is getting to the level where you need that extra functionality, connectivity, and sound quality to make your recordings, streams, and productions truly match your creative vision?

The URX series digital interfaces mark a significant step up in quality and flexibility from entry level interfaces while retaining their greatest attributes; a compact, unobtrusive design, simple connectivity, and ease of operation. As all-in-one solutions, all three URX models come equipped with onboard DSP mixing tools and effects integrated into the LCD panel's GUI, as well as a touch panel interface, carefully selected physical knobs, and support for compatible controllers, enabling a highly intuitive and speedy workflow.

Each URX model comes bundled with a comprehensive suite of music production software to support every stage of your workflow - from creation and audio management to system expansion. Backed by the rock-solid stability and reliability trusted by audio professionals worldwide, Yamaha and Steinberg provide the confidence you need to take on your next creative challenge.

  • Features:

    • USB Type-C audio/video interface with 32-bit/192kHz support, Multi-Stream Audio Driver, dual MAIN/SUB USB, HDMI input/capture/passthrough
    • 125 dB dynamic range (balanced output)
    • 4 microphone preamps with 78dB gain range and +48V phantom power
    • 4 Mic/Line (2 Combo/3.5mm headset mic, 2 Combo with Hi-Z), 1 AUX input (3.5mm Phone)
    • 4 TRS line outputs, 2 headphones (1 stereo phone/3.5mm headset, 1 stereo phone)
    • Input mixing channels: 4 mono + 4 stereo + 2 FX
    • Busses: 2 MIX (stereo) + 2 FX + 1 CUE + 1 STEREO
    • A 4.3" touchscreen with five control knobs
    • Assistive features: Auto Gain, Clip Safe, Simple/Standard mode, Scene Recall
    • Built-in DSP processor for professional sound and latency-free monitoring
    • microSD card recording up to 16 tracks and playback 2 tracks
    • HDMI-to-USB video/audio input with capture function and real-time HDMI passthrough

  • Specifications:

      I/O Connectors
    • Analog Input:
      - 4x Combo (1x Mic/Line/3.5 mm headset mic, 1x Mic/Line, 2x Mic/Line/Hi-Z)
      - 1x AUX (3.5mm Phone)
    • Analog Output: 4x TRS
    • USB to Host: 2x (USB Type-C, MAIN: 32-bit/SUB: 16-bit)
    • Phones:
      - 2x TRS
      - 1x mini headset phones (100mW+100mW @40Ω)
      *The first TRS Phones port and the 3.5mm mini port cannot be used simultaneously.
    • DC: 1x (Barrel type, DC power IN, AC Power Adapter PA-300)
    • microSD Card Slot: 1x
    • HDMI: 1x IN/1x THRU (Audio/Video input/capture/pass-through)

      User Interface
    • 4.3" touch screen
    • 5x rotary encoder (4x screen knob, 1x "Touch and Turn")

      Recording & Playback
    • USB: 18-track recording, 18-track playback
    • USB (SUB): 2-track recording, 2-track
    • microSD Card: Up to 16-track recording, 2-track playback

      Outline
    • Mixing Capacity:
      - Input Channels: 4x mono + 4x stereo + 2x FX
      - Mix Buses: 2x MIX (stereo) + 1x STEREO
      - Stereo Buses: 1x
      - FX Buses: 2x
      - Cue Buses: 1x
    • On-Board Processors: DSP Gate, Compressor, EQ, Sweet Spot Morphing Channel Strip (Comp & EQ), Guitar Amp Classics (Amp Simulator), PitchFix (Voice Changer), Ducker, Multi-Band Compressor, Compander, Delay, REV-X (Reverb)

      Other
    • Sampling Frequency Rate: 192kHz - 44.1kHz
    • Frequency Response: +0.0/-0.2dB ( 20Hz - 20kHz)
    • Dynamic Range:
      - [MIC/LINE/Hi-Z] 115dB
      - [MAIN OUTPUT] 125dB
    • Total Harmonic Distortion:
      - [MIC/LINE/Hi-Z] 0.0008%, 1kHz, 20kHz
      - LPF; [MAIN OUTPUT] 0.00036%, 1kHz, 20kHz LPF
    • Hum & Noise Level: -128dBu, A-Weighted
    • Crosstalk: 100dB, adjacent INPUT/MAIN OUTPUT channels, Input Gain= Min.
    • Gain Range: 78dB
    • Power Requirements: DC16V/2.4A, PA-300C AC power adapter (100V - 240V, 50Hz/60Hz)
    • Power Consumption: 38.4W (Off mode power: 0.1W)
    • Auto Power Off: 2 minutes, 5 minutes, 10 minutes, 15 minutes, 20 minutes or Never (factory default)
    • Dimensions: 9.6" x 3.1" x 7.2"
    • Net Weight: 4.2lbs

  • Item Includes:

    • 1x Start Guide
    • 1x Safety Guide
    • 1x Steinberg Software License Card (Cubase AI, WaveLab Cast, Basic Fx Suite, Steinberg Plus)
    • 1x USB-C to USB-C Cable (USB 2.0, 1.5m)
    • 1x AC Power Adapter (PA-300 including power cord)

  • GTIN:

    0889025171304
