Blonder Tongue ZHC-12A Passive Combiner 50-1000 MHz 12 Ports

    Questions? Ask a Markertek Expert:
    800-522-2025 Email

    Blonder Tongue ZHC-12A Passive Combiner 50-1000 MHz 12 Ports

    Item #: ZHC-12A   •   MFG #: ZHC-12A



    List Price:$72.13
    Our Price:$64.94

    free ship


    Availability: Usually ships in 3-10 business days
    i
    This item is currently out of stock and will ship the minute we receive it – typically 3-10 business days. Need it sooner? Expedited delivery options may be available. Email [email protected] or call customer service at 800-522-2025 and we'll make it happen.




      Share!





      The ZHC Series are professional quality, passive and active output combiners. These units are designed for use in headends to combine the outputs of multiple modulators and processors. The ZHC-12 has twelve (12) broadband input ports and one combined output port. The ZHCA-16c is a 16 port active combiner, providing over all unity gain and is commonly referred to as a "zero loss" combiner.


      • Features

        • Rack Mountable - 1 EIA (1.75") Rack Space
        • High Isolation
        • -20 dB Test Port

      • Specifications

        • Number of Inputs: 12
        • Frequency Range (MHz):40-1000
        • Input Level - Max (dBmV): NA
        • Output Level - Max (dBmV): NA
        • Cross Modulation (dBc): NA
        • Overall Unit Gain (dB): NA
        • Gain Control Range (dB): NA
        • Insertion Loss (dB): 40-450 MHz 17 dB 450-1000 MHz 20 dB
        • Isolation (dB): 30
        • Flatness (dB): 3
        • Impedance - All Ports (O): 75
        • RF Input & Output: "F" Female
        • Test Port: "F" Female
        • Dimensions (W x H x D): 19.0 x 1.75 x 2.88 in. 483 x 44 x 73 mm
        • Weight lbs: 2.0 lbs., 0.91 kg
