Hall Technologies EM-EDID-HD15 Pass-Through EDID Emulator

EM-EDID-HD15 - Overview

• Features:

  • Perfect for use with video splitters, switches and extenders.
  • Allows PC to 'see' an LCD in absence of DDC channel (common problem with extenders)
  • Can be powered from VGA input (if source complies is VESA compliant)
  • Power indicator LED lets user know if external power supply is needed
  • If source does not have power output, external power supply may be connected
  • Can be used alone or as a pass-through (use optional TM-75 terminator if you don't need pass thru ability
  • Passes RGB and Sync signals with no loss
  • Ships with default EDID that has most common resolutions
  • Can be programmed with other resolutions (separate programmer needed VS-2A-PRG)
  • Small size
  • Made in USA


• EDID Resolutions::

  • 640x480 @ 60 Hz, 67 Hz, 72 Hz, 75 Hz (Aspect 4:3)
  • 720x400 @ 70 Hz, 88 Hz (Aspect 16:9)
  • 800x600 @ 56 Hz, 60 Hz (Aspect 4:3)
  • 832x624 @ 75 Hz (Aspect 4:3)
  • 1024x768 @ 60 Hz, 70 Hz, 75 Hz (Aspect 4:3)
  • 1280x1024 @ 75 Hz, 85 Hz (Aspect 5:4)
  • 1152x870 @ 75 Hz (Aspect 4:3)
  • 1280x720 @ 60 Hz (Aspect 16:9 same as 720p)
  • 1280x960 @ 60 Hz (Aspect 4:3)
  • 1360x768 @ 60 Hz (Aspect 16:9 native on some LCD TVs)
  • 1920x1080 @ 60 Hz (Aspect 16:9 same as 1080p)


• GTIN:

  0724696529781
