Arri L10-C Color LED Fresnel Stand-Mount - Blue/Silver

ITEM #: ARR-L0-0003381 MFG #: L0.0003381

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

Our Price:

$6,750.00

Availability: Extended Lead Time. Email, Chat or Call Us for more details.
iAvailability Description Popup


    L0.0003381 - Overview

    The L10-C from ARRI is the brightest and largest L-Series lamphead to date. Its substantial 10 inch Fresnel lens and powerful output allow for more distant fixture placement and the wrapping of light around objects in a natural and pleasing way. At more than twice the brightness of the L7, the L10-C is also one of the brightest LED Fresnels on the market. Color temperature, tint and hue can be continuously adjusted from 2,800 K to 10,000K, between full plus or minus green and RGBW colors.

    Tuneability is the cornerstone of all ARRI LED fixtures and much like the L7 and L5, its smaller counterparts, the L10-C is fully color tuneable. With the ability to adjust the color temperature from 2,800 – 10,000 K, as well as the green/magenta point, users have complete control over the color output of the fixture.

    In a robust housing that combines aluminum with high-strength, fiberglass-reinforced thermoplastics, the L10-C is designed to withstand the stresses of diverse professional environments, from motion picture sets to television studios and everything in-between. This robust construction allows the L10-C to live up to the benchmark of rugged durability set by other ARRI lighting fixtures.

    Stand-Mount versions include the following base configuration: 28 mm Spigot (Junior Pin), Inline Switch, Integrated 5-Pin DMX In and Thru.

    Please Note: Barndoors are not included with L10 and have to be ordered separately.

    • Features:

      • Fully Tuneable from 2,800 K - 10,000 K
      • Plus/Minusgreen correction
      • Vibrant Color Selection (RGB+W Color Gamut)
      • Hue and Saturation Control
      • High Color Rendering
      • Low Power Consumption (400 W Nominal)
      • Fully Dimmable
      • True Fresnel Lens Light Characteristics
      • Onboard DMX In and Out
      • RDM Implementation
      • USB Mini Connection for Firmware Updates
      • Fan Mode Selection
      • powerCON TRUE1 Power Connector

    • Specifications:

      • Optical System: Focusable Fresnel
      • Lens Diameter: 274 mm / 10 inch
      • Beam Angle: 15° to 50° (Half Peak Angle)
      • Weight: Manual Version - 19.3 kg (42.5 lbs), Pole Op Version - 20.7 kg (45.6 lbs)
      • Handling: Adjustable Sliding Stirrup, High Strength Tilt Lock, Pole Operation Option (Pan, Tilt and Focus)
      • Mounting: 28 mm Spigot (Junior Pin)
      • Tilt Angle: +/- 90°
      • Power Supply Range: 100 to 250 V AC, 50/60 Hz
      • Power Consumption: 400 W (Nominal), 510 W (Maximum)
      • Power Connection: powerCON TRUE1 (Bare Ends / Schuko / Edison Cables Available)
      • White Light: 2,800 K to 10,000 K Continuously Variable Correlated Color Temperature
      • Colored Light: Full RGB+W Color Gamut with Hue and Saturation Control
      • Color Temperature Tolerance: +/- 100 K (nominal), +/- 1/8 Green-Magenta (nominal)
      • Color Rendition: CRI Average >95 (3,200K to 6,500K), TLCI Average >91
      • Green-Magenta Adjustment: Continuously Adjustable (Full Minusgreen to Full Plusgreen)
      • Dimming: 0 to 100% Continuous
      • Control: 5-Pin DMX In and Through, On-Board Controller, Mini-USB
      • Remote Device Management (RDM): DMX Setup, Hour Counter and Standard RDM Commands
      • Mini-USB Interface: DMX Setup, Fixture Status and Firmware Upgrade Through PC Software
      • Housing Color: Blue/Silver, Black
      • Ambient Temperature Operation: -20 to +45° C (-4 ? +113° F)
      • Protection Class: IP 20
      • Estimated LED Lifetime (L70): 50,000 hours
      • Estimated Color Shift Over Lifetime: +/- 5% K
      • Certifications: CE, FCC, GS, CB, cNRTLus
