Atlas TSD-GPN1200 Sound Masking Generator

ITEM #: ATL-TSD-GPN1200 MFG #: TSD-GPN1200

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$314.99

Our Price:

$253.99

Availability: In Stock
iAvailability Description Popup


    TSD-GPN1200 - Overview

    The TSD-GPN1200 sound masking generator is a great solution for basic masking systems. The analog topology design eliminates repeating cycles commonly found in other manufactures low cost digital designs. The TSD-GPN1200 allows selection between pink or white noise sources and incorporates a variable balanced output to match any amplifier input requirements.
    Additionally, a 4W, output is provided to power up to six masking loudspeakers tapped at .5W each. A variable hi-cut filter with operating range between 1kHz and8kHz at a slope of 6dB per octave supports equalization requirements for Sound Masking systems. Both outputs may be used simultaneously allowing large zones to be addressed with external equalization and amplification while a smaller zone is powered by the internal amplifier with spectrum control provided by the hi-cut filter.

    • Features:

      • Balanced Line Output Plus 4W, 70.7V Output
      • Adjustable Gain and Hi-Cut Filter
      • EQ & Gain Bypass for Line Output
      • Selectable Pink or White Noise Source
      • Stand Alone or Rack Mountable
      • Security Covers Included for All Rear Panel Controls
      • Meets Energy Star Standards
      • Compact Chassis Design

    • GTIN:

      0612079187935
