Atomos ATOMNJAV01 Ninja V 5 Inch 4Kp60 10bit HDR 1000nit Portable Monitor/Recorder

ITEM #: ATO-MNJAV01 MFG #: ATOMNJAV01

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order


Availability: Sold Out
iAvailability Description Popup


    ATOMNJAV01 - Overview

    Simply Connect, Switch and Stream

    The Ninja V ATOMNJAV01 is a small form factor, 1" thick 5" monitor recorder that offers amazing features to DSLR/Cinema customers. Its weight and its size is perfect for those looking for a recorder to unleash their camara's potential, for those looking for a flexible monitor that gives them the HDR capability for a better performance. Record up to 4Kp60 10-bit HDR video direct from your camera's sensor, over HDMI 2.0. Store edit-ready ProRes or DNxHR on affordable SSD drives and bypass your cameras internal compression and record time limits. A tiny 1TB AtomX SSDmini will give you 2.5 hrs of 4K recording.

    HDR/SDR perfection every time
    The Ninja screen displays a stunning 10+ stops of dynamic range in realtime from Log/ PQ/HLG signals. Clearly see your images in daylight on the near edge-to-edge anti-reflection screen. The display can be calibrated for perfect color accuracy every time, with playout to HDR or SDR TV sets.

    AtomOS Tools and Pocket Size Playback
    AtomOS gives simple tools for accurate set up and one-touch operation, ensuring a great recording every time. Of course, a recording isn't 100% complete until checked; AtomOS gives speedy playback, slow motion and frame-by-frame analysis for instant review.

    Edit, finish & upload on Mac & PC
    The recorded Ninja files are available immediately on your Mac or PC for editing. Tag while recording on the fly for direct-to-edit look-up with up to six streams, edited directly from the SSD in Final Cut Pro X, Adobe Premiere or Avid Media Composer. Video and gaming workflows are supported for the fastest path to your audience

    Record HDR Games
    4kp60 or HDp240 Game Recording just became fun and simple from any HDMI gaming unit. Place the Ninja V in-between your unit and the TV, and record for hours to off-the-shelf SSD drives. Auto HDR flags mean perfect TV set up every time! Show off your skills or check your game development on the most stunning video recorder ever built!

    • Features:

      • Xpand and transform Ninja V/V+ in to a 4 x HDMI input switcher
      • Overlay custom graphics, logos, lower thirds and content branding
      • Picture in Picture effect for any combination of inputs
      • WebCAST - Plug and Play UVC connection to your favourite software such as Zoom, MS Teams, Skype, OBS and more
      • BroadCAST - quality switching and recording in ProRes, DNx and option for h.265
      • MultiCAST - Simultaneously Record, Stream and output to local displays
      • Touch Screen and Physical buttons with LED status indicators
      • Separate HDMI outputs - Dedicated Program out and Multifunction on Ninja V/V+ for Multiview, Preview or Program
      • Audio Input and switching options with support for embedded, analogue inputs and Audio follow Video
      • Easy Quick deployment of reliable stand alone - Simply Connect, Switch and Stream

    • Specifications:

      • Physical Characteristics
      • Weight: 11.28oz (320g)
      • Dimensions (W x H x D ): 6" x 3.5" x 1" (151mm x 91.5 x 31mm)
      • Construction: Aluminium alloy chassis with ABS polycarbonate back plate
      • Mounting points: 1/4-20 UNCscrew mount; 1x top, 1x bottom
      • Operating power: 10 - 19W
      • Compatible batteries: NP-F series and supporting accessories
      • Input voltage (battery): 6.2V to 16.8V
      • Battery time (based on 2 x 7.4V): 5200mAh - up to 2hrs (monitor & record 4K +60p); 7800mAh - up to 3hrs (monitor & record 4K 60p)
      • Video Input/Loop Out: 1 x HDMI (2.0); Signal - Uncompressed true 10-bit or 8-bit 422 (camera dependent)
      • Video Output (Play Out): 1 x HDMI (2.0); Signal - Uncompressed true 10-bit or 8-bit 422 (playback file dependent)
      • Audio In/Out (48kHz PCM Audio): HDMI - 2 or 8ch 24-bit (camera dependent); Audio - Line in / Mic in / Headphone out 2ch 48kHz 24-bit
      • Headphone out: 3.5mm
      • Built-in speakers: Yes

        Touchscreen
      • Size: 5 inches
      • Resolution: 1920x1080
      • PPI: 427
      • Aspect ratio: 16:9 native
      • Color Gamut: REC709 HDTV
      • Look up table (LUT) support: 3D LUT (.cube format)
      • Anamorphic de-squeeze: 2x, 1.5x, 1.33x, Panasonic 8:3
      • Technology: SuperAtom IPS panel (capacitive touch), calibration to Rec.709 with optional calibration unit

        Remote Start/Stop
      • HDMI: Auto HDMI Trigger; Supported Protocols - Canon, Sony, Atomos Open Standard
      • Other: LANC control - Slave

        HDR
      • Supported Log formats: Sony SLog2 / SLog3, Canon CLog / CLog 2, Arri Log C, Panasonic Vlog, JVC JLog, Red LogFilm
      • HDR Recording (Gamut): Sony SLog / SLog2 / SLog3, Canon CLog / CLog2 / Clog3 / Arri Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320 / LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 / LogCEI1000 / LogCEI1280 / LogCEI1600, Panasonic Vlog, JVC JLog1, Red LogFilm / Log3G10 / Log3G12, FujiFilm Flog, PQ10k, HLG
      • HDR Monitoring (Gamma): Sony SGamut / SGamut3 / SGamut3.cine / BT2020 / Canon Cinema / DCI P3 / DCI P3+ / BT2020 / Panasonic V Gamut / Arri Alexa Wide Gamut / Rec709 / JVC LS300 / Red DragonColor / DragonColor2 / RedColor2 / RedColor3 / RedColor4 / RedWideGamut
      • HDR Monitoring (Gamut): Wide Color Gamut (SGamut / SGamut3 / SGamut3.cine / Canon Cinema / BT2020 / DCI P3 / DCI P3+ / Panasonic V Gamut / Arri Alexa Wide Gamut) mapping to Rec709 on screen Wide Color Gamut (SGamut / SGamut3 / SGamut3.cine / Canon Cinema / BT2020 / DCI P3 / DCI P3+ / Panasonic V Gamut / Arri Alexa Wide Gamut) mapping to Rec709 / BT2020 / DCI P3 on loop out
      • Bit depth: 10-bit (8+2 FRC)
      • Brightness: 1000nit (+/- 10% @ center)

        Recording
      • Pre-roll record: Yes (HD 8s, 4K 2s)
      • Supported media: 2.5" SSD/HDD compatibility depends on recording format, resolution and frame rate. Visit atomos.com/drives for list of tested and approved drives
      • Master caddy case: Master Caddy II (included) 3" x 4" x 0.5"(75mm x 105mm x 12mm)
      • Master caddy dock: 2.5" SATA to USB 2.0/3.0
      • Supported applications: Supported Applications FCPX/FCP7+ / Media Composer 5.0+ / Premiere 5.5+ EDIUS 6.0+ / Vegas Pro 10+ / Lightworks / Autodesk Smoke 2015
      • XML support: FCPX XML native, FCPX/Adobe limited supported with 3rd party conversion tools

    • Item Includes:

      • Ninja V unit
      • Master Caddy II x 1
      • 12V-3A AC power supply

    • GTIN:

      0814164021173
