Lilliput Q7-12G 7 Inch Full HD 12G 2000 nits Ultra Brightness On Camera Monitor with HDR/3D LUTs

ITEM #: LIL-Q7-12G MFG #: Q7-12G

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$959.00

Our Price:

$899.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    Q7-12G - Overview

    The Lilliput Q7-12G is a professional camera-top monitor that comes with an amazing 2000 nits Ultra Bright LCD screen, and was designed specifically for photography and film makers with a focus on outdoor video and film. This 7 inch LCD monitor has 1920x1200 Full HD native resolution and 1200:1 high contast providing superior picture quality, and supports 4K HDMI and 12G-SDI signal inputs and loop outputs. The Lilliput Q7-12G can receive 2 x 12G-SDI signals and diaplay them at the same time through the picture-in-picture function, the size and position of which can be adjusted. It also suppoerts HDMI signals up to 4K 60Hz making it compatible with the latest DSLR cameras with an HDMI 2.0 interface.

    • Features:

      • Ultra Brightness 2000 nits
      • HDR
      • 3D-LUT
      • 12G-SDI Broadcast
      • HDMI 2.0 Video Shooting
      • 12G-SDI Picture-In-Picture
      • Waveform
      • Audio Vector
      • Peaking
      • Histogram
      • Level Meter
      • False Color

    • Specifications:

      • Display:
      • Panel: 7 Inch
      • Physical Resolution: 1920 x 1200
      • Aspect Ratio: 16:10
      • Brightness: 2000 nit
      • Contrast: 1200:1
      • Viewing Angle: 170° / 170° (H/V)
      • HDR: ST2084 300/1000/10000/HLG
      • Supported Log Formats: SLog2 / SLog3 / CLog / NLog / ArriLog / JLog or User
      • Look up Table (LUT) Support: 3D LUT (cube format)

        Signal Input:
      • SDI: 2 x 12G-SDI
      • HDMI: 1 x HDMI 2.0
      • Tally: 1

        Signal Loop Outputs:
      • SDI: 2 x 12G-SDI
      • HDMI: 1 x HDMI 2.0

        Signal Formats:
      • SDI: 2160p 60/50/30/25/24, 1080p 60/50/30/25/24, 1080pSF 30/25/24, 1080i 60/50, 720p 60/50
      • HDMI: 2160p 60/50/30/25/24, 1080p 60/50/30/25/24, 1080i 60/50, 720p 60/50

        Audio In/Out:
      • SDI: 16ch 48kHz 24-bit
      • HDMI: 8ch 24-bit
      • Ear Jack: 3.5mm
      • Built-In Speakers: 1

        Power:
      • Input Voltage: DC 7-24V
      • Power Consumption: <20W (12v)

        Environment:
      • Operating Temperature: 0°C - 50°C
      • Storage Temperature: -20°C - 60°C

        Other:
      • Dimension: 186mm x 128mm x 32.5mm
      • Weight: 785g

    • Item Includes:

      • 1x Q7-12G Monitor
      • 1x 12V 2A DC Power Adapter
      • 1x Suitcase
      • 1x U-shaded Bracket
      • 1x VESA 75mm Battery Plate (Sony NP-F Series)
      • 1x Tally Connector

    • GTIN:

      6950821601969
