Blustream DA22DIG 2x2 Digital & Analog Dante Converter - Supports 44.1 48 & 96kHz with Sample Rates at 24 Bit

DA22DIG - Overview

• Features:

  • Encodes 2ch analog audio or digital audio to Dante digital signal
  • Decodes a Dante digital signal to 2ch analog audio and digital audio
  • Selectable digital audio between optical toslink and coaxial RCA inputs
  • Configurable MIC audio input with 48V phantom power
  • Independent sensitivity control for input channels, and gain control for output channels
  • Supports: 44.1, 48 & 96kHz sample rates @ 24 Bit
  • Configurable Dante device latency (supports 1, 2 or 5ms configurable using Dante Controller)
  • Supports AES67 RTP audio transport
  • Features Class 3 IEEE 802.3af PoE for powering of product from any PoE switch
  • Supports power via 12V DC adapter (supplied) for when network switch does not support PoE


• Specifications:

  • Audio Input Connectors: 2x Analog Balanced/Unbalanced, 6-Pin Phoenix connector, 1x Optical (S/PDIF), 1x Coaxial (RCA)
  • Audio Output Connectors: 2x Analog Balanced/Unbalanced, 6-pin Phoenix connector, 1x Optical (S/PDIF), 1x Coaxial (RCA)
  • Network Connectors: 1x PoE Danter Ethernet Connection (RJ45)
  • Configuration Switches: 4x 16 Level Rotary Dials, 3 x 3-Position Switch
  • Casing Dimensions (LxWxH): 135mm x 80mm x 38mm
  • Shipping Weight: 0.5kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature: - 4°F to 140°F (- 20°C to 60°C)
  • Power Supply: Class 3 IEEE 802.3af POE PD or 12V/1A DC, Screw Type Connector


• Item Includes:

  • 1x DA22DIG
  • 1x Mounting Kit
  • 1x 12V / 1A DC Power Supply
  • 1x Quick Reference Guide


• Warranty:

  • 1-Year Limited Warranty
