Cobalt RM20-9904-D-HDBNC Single Width 20-Slot openGear Frame Rear I/O Module for 9904 Cards

ITEM #: CB-RM20-9904-D-H MFG #: RM20-9904-D-HDBNC

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

Our Price:


Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup

    RM20-9904-D-HDBNC - Overview

    The Cobalt Digital RM20-9904-D-HDBNC is a single wide 20-Slot Frame Rear I/O Module with (6) 12G/6G/3G/HD/SD/SD-SDI Inputs, (8) 12G/6G/3G/HD/SD/SD-SDI Processed Outputs, (4) AES Outputs, GPIO/COMM (HD-15 connector), HDMI 2.0 Output (type A standard connector) and 100/1000 BaseT Ethernet Port (All coaxial connectors HD-BNC.)

    This module mates with the Cobalt 9904-UDX-4K 12G/6G/3G/HD/SD UHD Up/Down/Cross Converter/Frame Sync/Embed/De-Embed Audio Processor card and is Cobalt's next generation of advanced scaler/frame synchronizers for the openGear platform. The 9904-UDX-4K upconverts 12G/6G/3G/HD/SD to either UHD1 3840x2160 Square DIvision Multiplex (SDM) or Two-Sample Interleave (2SI) quad 3G-SDI based formats, or can output ST 2082 12G-SDI for single-wire 4K transport. With both 12G-SDI and quad 3G-SDI inputs, the 9904-UDX-4K can downconvert 12G and quad UHD. The 9904-UDX-4K provides an HDMI 2.0 output for economical 4K video monitoring. The 9904-UDX-4K offers numerous options, including SDR-to-HDR conversion and color correction.

    Please Note! This is the Rear Module only! Card is sold seperately!

    • Features:

      • 20-Slot Frame Rear I/O Module (Standard-Width)
      • (6) 12G/6G/3G/HD/SD/SD-SDI Inputs
      • (6) 12G/6G/3G/HD/SD/SD-SDI Processed Outputs
      • (4) AES I/O, GPIO/COMM (Micro D25)
      • 100/1000 BaseT Ethernet Port (All coaxial connectors HD-BNC.)
