Chauvet Cloud 9X IP Professional IP-Rated Low-Lying DMX Fogger for On-Stage or Ballrooms - Up to 3230 Square Feet

ITEM #: CHVT-CLOUD9XIP MFG #: CLOUD9XIP

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$4,961.00

Our Price:

$4,322.00

Availability: In Stock - Ships Factory Direct, Typically in 6 Business Days.
Please Email, Chat or Call (800) 522-2025
iAvailability Description Popup
  • Shipped truck freight.


CLOUD9XIP - Overview

Ideal for professional touring productions, event stages, and ballrooms requiring a reliable, continuous low-fog effect without the logistical challenges of dry ice!

Discover key upgrades from the original Cloud 9, including a lighter, more compact design, simplified power setup, an RF remote control, updated housing with integrated water reservoir, USB-C connectivity for future updates, and improved accessory storage! Designed for rentals and live productions, the Chauvet Cloud 9X IP delivers more flexibility and easier operation.

Cloud 9X IP is a compact low-lying fogger that produces high-impact floor-hugging fog ideal for stages and ballrooms. No refrigeration, dry ice or CO² is needed, making for easy and safe operation that requires no special handling, licensing, or training.

Cloud 9X IP creates continuous output using only LLG low-lying fog fluid and tap water (no need for distilled!). Taking full advantage of its new ability to use water from a faucet, Cloud 9X IP features a rear fitting that accepts a regular garden hose for automated refilling as water is depleted.

With a fast five-minute heat-up time and integrated water drainage system with a durable brass fitting that withstands repeated use, Cloud 9X IP setups and cleanups are always quick, easy, and reliable. Convenient control is available in any setting or application, via full-color onboard control display, RDM, DMX, or its included wireless RF handheld remote.

Cloud 9X IP features an upgraded housing that is not only inherently corrosion resistant, but also signficantly lighter than the previous Cloud 9 model that it replaces (total weight has been reduced from ~120lbs to ~75lbs). Its new housing is also stackable (up to 3 tall), making for easy transportation by truck, and features a removable rear cover for storing accessories, keeping everything self-contained in the unit.

**Required Accessories (sold separately):
• Fog Fluid-LLG
• Compatible Mounting Options - Floor Mount/Positioning only w/locking wheels

  • Features:

    • High-Impact Low-Lying Fog: This compact, professional fogger creates a dramatic low-lying fog effect perfect for stages and ballrooms.
    • Outdoor and Wet Environment Use: Designed to be suitable for temporary use in outdoor or wet conditions.
    • Continuous Operation and Large Coverage: Delivers continuous fog output capable of covering a substantial 3,230 square foot area.
    • Ultrasonic Technology: Ultrasonic agitators combine distilled water with fog fluid to create the dense, low-lying effect.
    • Integrated Touring Case: It ships in a rugged, integrated flight case with locking casters, making it ideal for touring and rental applications.
    • Flexible Control Options: Control the unit easily via the onboard full-color display, a wireless remote, or DMX.
    • Fast Cleanup System: An integrated water drainage system simplifies the cleanup process, saving you time and effort.
    • CO2 Style Effect: Produces a CO²-style effect that lasts for several minutes before dissipating when used with LLG fluid.
    • No Dry Ice or CO² Needed: Operates without dry ice or CO², eliminating the need for special licensing or training.
    • Simple Software Updates: Features a convenient USB-C port for easy software uploads.

  • Specifications:

      Dynamic Effects
    • Fan Performance: 81 cfm
    • Low Fluid Shutdown: Yes

      Construction/Physical
    • Dimensions:
      - Without Back Cover: 30.00" x 17.36" x 19.22" (762mm x 441mm x 488.1mm)
      - With Back Cover: 37.72" x 17.36" x 19.22" (958mm x 441mm x 488.1mm)
    • Output Nozzle (Outer Diameter): 4.76" (121mm)
    • Hose Length (Fully extended): 11ft (3.4m)
    • Weight: 76.6lbs (34.75kg)
    • Exterior Color: Black
    • Housing Material: Aluminum alloy, High-impact flame-retardant polymer

      Water Tank Capacity
    • Tank Capacity (Low-lying Fog Fluid): 0.8 gal (3 l)
    • Fog Fluid Consumption: 25 mL/min (0.88 fl oz/min)
    • Fog Fluid Runtime (Fog Fluid Tank,3 L): 2 hr
    • Water Consumption: 184.7 mL/min (6.25 fl oz/min)
    • Water Runtime (w/ Total Water Tank, 27.7 L): 2.5 hr

      Connections
    • Power Input: Seetronic Powerkon IP65
    • Data Connectors: 3-pin/5-pin IP rated
    • Cable Length (power): 5ft (1.5m)
    • Firmware Upgrades: USB type-C

      Control
    • Control Protocol: DMX, RDM, Wireless Remote
    • DMX Channels: 3
    • Modes/Personalities: 1 personality (3ch)
    • On-Board Control: Yes
    • Included Remote: Yes

      Electrical
    • Input Voltage: 120VAC, 60Hz
    • Input Voltage: 230VAC, 50Hz
    • Power and Current: 1960W, 17.5A @ 120V, 60Hz
    • Power and Current: 1281W, 5.59A @ 230V, 50Hz
    • Heat-up Time: 5 min
    • Breaker Size: 10A, 250V

  • Item Includes:

    • 1x Cloud 9 X IP
    • 1x Seetronic Powerkon IP65 power cable
    • 1x RF remote (2-button)
    • 2x Hose clamps, 6" (152mm) diameter
    • 1x Barbed hose adapter (0.5")(13mm) diameter
    • 2x Barbed hose adapter hose clamps - 1" (25mm) diameter
    • 1x 6ft (2m) output hose, 5" (130mm) diameter
    • 1x Removable rear cover
    • 1x Hose coupler, 5" (130mm) diameter
    • 1x Floor nozzle, 5" (130mm) diameter
    • 1x Overfill hose (polyurethane, 6mmOD, 4mm ID, 80" (204cm))
    • 1x Quick Reference Guide

  • GTIN:

    0781462229658
