Cleerline D50125MOM4P SSF Duplex OM4 Plenum 50/125 Multimode Indoor/Outdoor Cable - Violet - 1000 Foot

D50125MOM4P - Overview

• Features:

  • Zipcord construction - easy to separate strands
  • High mechanical strength, superior fatigue (Nd = 30)
  • Compatible with common connector systems for 50/125 multimode fibers
  • Up to 10,000x the bend longevity of traditional fiber
  • Integral SSF™ coating provides glass protection
  • Increased safety due to incredible bend insensitivity
  • Exclusive 250 æm Soft Peel acrylate


• Specifications:

  Fiber
  • Number of Fibers: 2
  • 50/125 Multimode OM4
  • 250um "Soft Peel" coating (1 = Blue, 2 = Orange)
  • Color Coding per TIA/EIA 568C

    Jacket
  • Riser Rated PVC/Plenum Rated PVC + UV/LSZH
  • 3.0mm unit diameter
  • Violet jacket = Multimode fiber OM4
  • Sequential footage markings
  • Kevlar (Plenum + water blocking yarns Indoor/Outdoor)

    Physical Data
  • Storage Temperature Range: -40°F - 185°F (-40°C - 85°C)
  • Operating Temperature Range: -4°F - 167°F (-20°C - 75°C)
  • Max Tensile Load for Installation: 1000(225) N(lbf)
  • Max Tensile Load Long term: 500(112) N (lbf)
  • Min. Bend Radius, Unloaded: 1 x OD (1 x 3.0mm)
  • Cable Outside Diameter, Nominal: 3.0mm x2 (6.2mm)
  • Cable Package: 1000ft (304.8m) Reel
  • Rating: FT4-Riser/FT6-Plenum/LSZH
  • Crush Resistance (TIA/EIA 455-41A): 100kgf/mm
  • Impact Resistance (TIA/EIA 455-25B): 1500 Impact cycles
  • Flexing @ 90° (TIA/EIA 455-104A): 2000 flexing cycles


• Item Includes:

  • 1x Cleerline D50125MOM4P SSF Duplex OM4 Plenum Multimode Indoor/Outdoor Cable - Magenta - 1000 Foot


• Warranty:

  • Lifetime


• GTIN:

  0609385519086
