Camplex opticalCON MTP NO12FDW-A to (12) ST Female Single Mode Breakout Rack Mount

ITEM #: CMX-1RM-MTP12ST MFG #: CMX-1RM-MTP12ST

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$938.95

Our Price:

$845.49

Availability: 2+ Weeks.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.
  • Extended Lead Time; estimated delivery in September.


CMX-1RM-MTP12ST - Overview

Camplex CMX-1RM-MTP12ST Rack Mountable Breakout Boxes allow for 12 channel fiber optic cable adaption from opticalCON MTP NO12FDW-A connectors to 12 ST female single mode chassis mount connectors. Lightweight anodized front and back aluminum box and power coated top and bottom includes dust caps. Camplex breakout boxes are a convenient way to breakout your MTP cables to a variety of other connectivity formats and are ideal for rigorous indoor use.

  • Features:

    • Lightweight 1RU aluminum enclosure
    • High-Quality Neutrik connectors
    • Connector gaskets are color-coded according to Fiber Mode for easy identification
    • Low-loss opticalCON MTP connectors
    • Internal Camplex MTP breakout cable
    • All channels are marked on the front and back of the enclosure for easy identification

  • Specifications:

    • Dimensions: 19"W x 9.125"D x 1.5"H

      Camplex Single Mode MTP APC connector
    • Insertion Loss: <0.35dB
    • Return Loss: >60dB

      ST Connectors
    • Insertion Loss: ≤0.2dB
    • Lifetime: 1000 Mating Cycles

  • Warranty:

    • 1 Year
