Chauvet COLORado 3 Quad Zoom IP65 RGBL LED Fixture - 7x LEDs - DMX and RDM Control

COLORADO3QZL - Overview

A wash light that can withstand the elements - Perfect for touring productions and outdoor festivals!

• Features:

  • Versatile RGBL LED Zoom Wash: A high-performance fixture designed for touring, rental, and production applications in any environment.
  • Superior Color Mixing: Experience high-power output with exceptionally smooth and even color blending.
  • Wide Zoom Range: Achieve a smooth and fast zoom from a tight 3.9° beam to a wide 52.6° wash.
  • All-Environment Operation: IP-rated power and DMX connections ensure reliable performance in any indoor or outdoor setting.
  • Flexible Mounting Options: Mount the fixture effortlessly with traditional clamps, a quick-connecting omega bracket, or a split yoke floor stand.
  • Selectable Dimming Curves: Choose from multiple smooth dimming curves for enhanced programming versatility.
  • Advanced Onboard Control: An OLED display with backlit buttons provides easy navigation, a dedicated focus mode, and password protection.


• Specifications:

  Optical
  • Light Source: 7 LEDs (quad-color RGBL), 8.4 to 13W, (2.7 A), 50,000 hours life
  • Color Temperature (range): 2800K - 8000K
  • Color Temperature (at full): 5882K
  • CRI (3200K): 83
  • Beam Angle: 3.9° - 38.5°
  • Field Angle: 6° - 52.6°
  • Cutoff Angle: 7.3° - 58.9°
  • Zoom Range: 3.9° - 52.6°
  • Lumens (3.2°): 3350
  • Lumens (39.9°): 5974
  • Illuminance (3.9°): 27,567 lux @ 5m
  • Illuminance (38.5°): 657 lux @ 5m
  • Selectable PWM: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 25,000Hz

    Dynamic Effects
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Zoom: Motorized
  • Focus: Electronic
  • Strobe Rate: 0Hz - 30Hz
  • Standalone Color Mixing: Yes
  • Color Temperature Presets: Yes
  • Dim Modes: 4
  • Dim Curves: 4
  • Built-in Automated Programs: Yes

    Construction/Physical
  • Dimensions: 16.34" x 10.94" x 8.30" (415mm x 278mm x 210.84mm)
  • Weight: 14.2lbs (6.4kg)
  • Exterior Color: Black
  • Housing Material: Magnesium diecast
  • Accessory Holder/Gel Frame Size: 7.5" (190.5mm)

    Connections
  • Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Power Output: Seetronic Powerkon IP65
  • Data Connectors: 5-pin XLR
  • Cable Length (power): 5ft (1.5m)
  • Software Connection: USB

    Control
  • Control Protocol: DMX, RDM
  • DMX Channels: 1CH, 5CH1, 5CH2, 7CH, 11CH, 12CH, 13CH, 16CH or HSV
  • Modes/Personalities: 9 personalities (1CH, 5CH1, 5CH2, 7CH, 11CH, 12CH, 13CH, 16CH, HSV)

    Electrical
  • Input Voltage: 100V - 240VAC, 50/60Hz (auto-ranging)
  • Power Linking: 5 units @ 120V; 9 units @ 208V; 10 units @ 230V
  • Power and Current:
    - Electrical Detail: 258W, 2.23A @ 120V, 60Hz
    - Electrical Detail 2: 255W, 1.29A @ 208V, 60Hz
    - Electrical Detail 3: 260W, 1.18A @ 230V, 50Hz

    Certifications/Qualifications
  • Certifications: CE, MET, FCC
  • IP Rating: IP65, outdoor/wet, with pressure equalizing M12 GORE valve
  • Noise Levels:
    - Noise Level (Idle): 20.0dB(A) @ 1m
    - Noise Level (Auto): 30.3dB(A) @ 1m
    - Noise Level (On): 40.9dB(A) @ 1m
    - Noise Level (Off): 19.4dB(A) @ 1m
    - Noise Level (Silent): 21.0dB(A) @ 1m
    - Noise Level (Max): 37.3dB(A) @ 1m
  • Temperature (Ambient): -4°F - 122°F (-20°C - 50°C)


• Item Includes:

  • 1x COLORado 3 Quad Zoom
  • 1x Seetronic Powerkon IP65 power cord
  • 1x Omega bracket
  • 1x Gel frame holder (7.5"/190.5mm accessories)
