EAW Radius RSX18 Self-Powered Loudspeaker - 1000W
  • EAW Radius RSX18 Self-Powered Loudspeaker - 1000W
  • EAW Radius RSX18 Self-Powered Loudspeaker - 1000W
  • EAW Radius RSX18 Self-Powered Loudspeaker - 1000W
  • EAW Radius RSX18 Self-Powered Loudspeaker - 1000W
  • EAW Radius RSX18 Self-Powered Loudspeaker - 1000W

Questions? Ask a Markertek Expert:
800-522-2025 Email

EAW Radius RSX18 Self-Powered Loudspeaker - 1000W

Manufacturer: Eastern Acoustic Works

Item #: EAW-RSX18   •   MFG #: RSX18




Our Price:$2,517.00

free ship


Availability:
More on the way, usually ships in 3-10 business days
i
This item is currently out of stock and will ship the minute we receive it – typically 3-10 business days. Need it sooner? Expedited delivery options may be available. Email [email protected] or call customer service at 800-522-2025 and we'll make it happen.



    California Residents:
    8pt-triangleWARNING:
    Cancer and Reproductive Harm - www.P65Warnings.ca.gov





    Designed to streamline setup and deliver maximum results in minimum time, RADIUS couples unique and intelligent features with EAW's signature acoustical design to deliver solutions for rental firms and system integrators. The powerful RSX18 18? subwoofer is ideal for production applications, offering push-button cardioid operation for added sonic control. The RSX18 features onboard electronics (1000W per channel) and ultra-wide ports that drastically reduce low-frequency turbulence. EAWmosaic app provides total system optimization from anywhere in the venue, plus intuitive room design and prediction in a single, comprehensive application. With the proven sonic performance of EAW's acoustic design and DSP mastery plus full Dante integration across the line, RADIUS delivers an intelligent and flexible system to fit any budget.

    Perfect Applications Include:
    House of Worship
    Theatres, Auditorium and Performing Arts Centers
    Live Music Clubs
    Corporate AV Houses
    Live Production/Regional Rental Houses
    Dry Hire

    EAW touring subwoofers harness pioneering technologies in acoustics, component design and signal processing to deliver extreme bandwidth, tonal consistency and storied impact.

    The complete range includes customized companion solutions for optimal pairing with specific full-range products as well as more universal and now ubiquitous solutions that have largely evolved from the legendary SB1000. From the compact SBX220 through the thunderous SB2001 - the complete family of subwoofers offers extraordinary performance for a comprehensive variety of live applications.


    • Features

      • Push-button cardioid operation provides directivity to lower excess low-frequency energy on stage.
      • Extremely approachable EAWmosaic iOS app delivers system prediction, control and monitoring from any location in the venue.
      • Proven EAW acoustical design and DSP including Focusing and DynO provides a pristine impulse response at all output levels.
      • Integrated Dante networking (with loop-thru) on all models including Analog redundancy capability.

    • Specifications

      • CONFIGURATION
      • Subsystem:
      • Transducer: LF - 1 x 18 in cone, 3 in voice coil
      • Loading: LF - Vented
      • Operating Mode:
      • Amplifier Channels: Single-amp LF
      • Signal Processing: DSP w/ DynO™

        PERFORMANCE
      • Operating Range: 30 Hz to 140 Hz
      • Nominal Beamwidth: Horizontal 360°; Vertical 360°
      • Calculated Axial Output Limit (whole space SPL): Average: 122 dB (whole space), 128 dB (half space); Peak: 128 dB (whole space), 134 dB (half space)
      • Input Type: Electronically balanced
      • Max Input Level: 21dBu
      • Impedance: 20 kOhm (balanced)
      • Input Wiring: XLRF, Pin 1 chassis, pin 2 +, pin 3 - Separate loop-thru XLRM (for analog signal only)
      • Input Selection: Analog, Dante
      • Amplifiers & Processing (LF) Type: Modified Class D
      • Maximum Output: 1000W
      • Driver Protection: Integral DSP limiting
      • AC Mains (nominal) Connector: Neutrik PowerCon
      • Input: 100 V to 240 V
      • Frequency: 50 Hz to 60 Hz
      • Power Consumption: Idle - 50 W
      • Peak Draw: 1400 W
      • Controls/Communication Connections: 2x Neutrik etherCON, RJ-45
      • Protocols: Ethernet/Dante
      • Software: EAWmosaic™ (available on the App Store)
      • Indicators: LCD Screen on amplifier panel for UI, Logo LED (User-definable behavior)
      • User Controls: Push-button Rotary Encoder

        PHYSICAL
      • Dimensions (inches/millimeters):
      • Height: 20.25/514
      • Width: 36/919
      • Depth: 31/790
      • Weight (pounds/kilograms): 93.6/42.5
