FUZ131 - Overview

The FUZE PROFILE CW™ is an automated LED framing fixture designed for trade show, stages, television and a wide array of AV event applications. The 91CRI 380W White LED engine ensures accurate color reproduction while delivering a powerful output of 11,000 lumens. Designed to illuminate objects like exhibits and banners, texture areas and key light persons with its flat field and accurate framing it has many practical applications where a fully automated ellipsoidal fixture is required. A rotating gobo wheel of breakups,two color wheels featuring solid colors and correction filters plus and Iris round out its comprehensive feature set.

  • Features:

    • High Efficiency 380W White LED Engine, 91CRI
    • Dual Color Wheel (Solids and Color Corrections)
    • Rotating Gobo Wheel
    • Full Blackout Framing System
    • Iris and Frost
    • Wide Zoom Range from 9° to 43°

  • Specifications:

    • Source:
    • 380W 6,000K White LED Engine, 91CRI
    • 30,000 Hour Average LED Life*
    • *Test lab conditions. May vary depending on several factors including but not limited to: Environmental Conditions,
    • Power/Voltage, Usage Patterns (On-Off Cycling),Control, and Dimming.

      Photometric Data:
    • 11,000 Total Lumen Output

      Effects:
    • 9° - 43° Motorized Zoom
    • 4 Rotating Full Blackout Framing Blades, +/- 45 Index
    • Variable Frost Filter
    • Motorized Iris
    • Variable 16-bit Dimming Curve Modes
    • High Speed Electronic Shutter and Strobe
    • Adjustable LED Refresh Rate Frequency

      Color:
    • 2 Color Wheels
    • 7x Solid Colors
    • 7x Color Correction and UV

      Gobos:
    • 1 Gobo Wheel
    • 7 Rotating / Indexing Interchangeable Glass Gobos

      Control / Connections:
    • 2 DMX Channel Modes (26 / 40)
    • 16-bit Pan, Tilt, and Dimming Control
    • Motorized Focus
    • DMX, RDM Protocol Support
    • 4 Button Touch Control Panel
    • Full Color 180° Reversible LCD Menu Display
    • 16 Bit Resolution Adjustable Movement
    • Hibernation Mode (Power Save)
    • 5pin DMX In/Out
    • IP65 Locking Power Cable In/Out
    • With Wired Digital Communication Network

      Size / Weight:
    • Length: 15.9"" (408mm)
    • Width: 9.9"" (252mm)
    • Vertical Height: 27.4"" (698mm)
    • Weight: 51.4 lbs. (23.3kg)

      Electrical / Thermal:
    • AC 100-240V - 50/60Hz
    • 590W Max Power Consumption
    • 14°F to 113°F (-10°C to 45°C)
    • BTU/hr (+/- 10%) 2011.9

      Approvals / Ratings:
    • CE
    • cETLus
    • IP20

  • Item Includes:

    • 1x FUZ131 DJ Lighting
    • 1x Power Cable

  • Warranty:

    • 2 Year

  • GTIN:

    0810008260234
