Elation Professional SEV014 SEVEN Batten 14 1.2 Foot (0.4m) Seven Color Batten Wash Luminaire

ITEM #: ELAT-SEV014 MFG #: SEV014

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$1,500.00

Our Price:

$1,200.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    SEV014 - Overview

    The Elation Professional SEVEN Batten 14™ is a seven color 1.2 foot (0.4m) long batten wash luminaire with (12) 25W 7-in-1 RGBAW + Lime + UV (395nm) LEDs. Features include individual hue, saturation, and intensity control, special RGB SEVEN 3 channel mode (RGB + dynamic white, amber, lime, and UV), 2 pixel mapping zones with pixel flip mode, smooth color mixing, 12 internal programs with speed and fade control, 64 unique 7-color macros, selectable dimming curve modes, adjustable LED refresh rate and gamma brightness for flicker free operation for TV and FILM, DMX Art-Net, Kling-Net, and RDM (Remote Device Management) protocol support, 3/5pin DMX, RJ45 etherCON, and power in/out connections, a 220° manual tilt adjustable mounting bracket, OLED menu display with a 4-button control panel, a multi-voltage universal auto switching power supply (100-240v), a rugged powder coated die-cast aluminum exterior, and an integrated gel / frost filter slot.

    • Features:

      • 1.2 Foot (0.4m) Seven Color Batten Wash Luminaire
      • (12) 25W 7-in-1 RGBAW + Lime + UV (395nm) LEDs
      • Individual Hue, Saturation, and Intensity Control
      • Special RGB SEVEN 3 Channel Mode (RGB + Dynamic White, Amber, Lime, UV)
      • 2 Pixel Mapping Zones with Pixel Flip Mode
      • Smooth Color Mixing, Internal Programs with Speed and Fade Control
      • 64 Unique 7-Color Macros
      • Selectable 16-bit Dimming Curve Modes
      • DMX Adjustable LED Refresh Rate
      • Adjustable LED Gamma Brightness
      • Flicker Free Operation for TV and FILM
      • Art-Net, Kling-Net, and RDM Protocol Support
      • 220° Manual Tilt Adjustable Mounting Bracket
      • Rugged Powder Coated Die-Cast Aluminum Exterior
      • Integrated Gel / Frost Filter Slot

    • Specifications:

      • Source
      • (12) 25W 7-IN-1 RGBAW + Lime + UV LEDs
      • 50,000 Hour Average LED Life*
      • *May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

        Effects
      • Individual Hue, Saturation, and Intensity Control
      • Special RGB SEVEN 3 Channel DMX Mode (RGB + Dynamic White, Amber, Lime, UV)
      • 2 Pixel Mapping Zones with Pixel Flip Mode
      • 12 Internal Program Macros with Speed and Fade Control
      • 64 Unique 7-Color Macros
      • Selectable 16-bit Dimming Curve Mode

        Color
      • RGBAW + Lime + UV (395nm)

        Control / Connections
      • 12 DMX Channel Modes (22 total channels)
      • DMX and Manual Control
      • 4 Button Control Panel
      • 180° Reversible OLED Menu Display
      • DMX Adjustable LED Refresh Rate (900-28,800 (Hz)
      • Adjustable LED Gamma Brightness (2.0, 2.2, 2.4, 2.8)
      • Art-Net, Kling-Net, and RDM Remote Device Management) Protocol Support
      • 3/5pin DMX, RJ45 etherCON, and Power In/Out
      • With Wired Digital Communication Network

        Size / Weight
      • Length: 14.0" (355.6mm)
      • Width: 4.5" (114.3mm)
      • Vertical Height: 9.0" (228.6mm)
      • Weight: 17.0 lbs. (7.7kg)

        Electrical / Thermal
      • AC 100-240V - 50/60Hz
      • 201W Max Power Consumption
      • 5°F to 113°F (-15°C to 45°C)

        Approvals / Ratings
      • CE | cETLus | IP20

    • Item Includes:

      • 1x Elation Professional SEVEN Batten 14
      • 1x Power Cable

    • Warranty:

      • 2 year

    • GTIN:

      0837874008418
