Thor Fiber F-4A-XLR-B-PHP-TXRX 4 Bi-Directional XLR Analog Audio Over Fiber Tx/Rx Kit - Singlemode - LC/PC

ITEM #: F-4A-XLRBPHPTXRX MFG #: F-4A-XLR-B-PHP-TXRX

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$3,294.00

Our Price:

$2,745.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


F-4A-XLR-B-PHP-TXRX - Overview

Introducing the Thor Fiber F-4A-XLR-B-PHP-TXRX 4 Bidirectional Balanced Analog XLR Audio with 48V DC phantom fiber optic Transmitter/Receiver Converter Kit. Absorbing the advantages of similar products at home and abroad, combined with the actual demand of the market, Thor launched the broadcast XLR balanced audio fiber optic converter, using FPGA, digital code, and clock recovery technology, with high integration, high stability, and high intelligent noise reduction system. To ensure the reliability, consistency, and stability of the equipment for soft rising or falling ramp waves and simulated squelch with a 100dB signal-to-noise ratio (SNR) without popping sound operation. CWDM technology realizes multi-channel signal transmission. The product has stable performance, simple installation, easy maintenance, and it is suitable for large-scale commercial operation.

  • Features:

    • Each audio channel supports a 48V phantom power switch with an adjustable phantom power control.
    • FPGA digital code and clock recovery technology for enhanced signal integrity.
    • Automatic high-pass filter to isolate DC offset.
    • Intelligent noise reduction system with soft rising/falling ramp waves and simulated squelch, providing a 100dB signal-to-noise ratio (SNR) without popping.
    • Audio interface features Level 3 lightning protection.
    • Standard single-mode fiber optic transmission distance of up to 20 km.
    • LED status indicator lights to monitor the operating status of the devices.
    • Plug-and-play functionality with no setup required.
    • Devices are sold as a pair; note that the transmitter and receiver are distinguished and must be used accordingly.

  • Specifications:

      Fiber
    • Wavelength: 1310nm & 1470nm - 1610nm (selected according to the function of the device)
    • Transmitter Power: > -7dB
    • Receiver Sensitivity: > -24dB
    • Fiber Connector: LC/PC - singlemode

      Audio Parameter
    • Signal Level: 08Vp-p - 8Vp-p
    • Dynamic Bandwidth: 101dB
    • Total Harmonic Distortion (THD): -90dB
    • Sampling Frequency: 192kHz
    • Audio A/D Sampling: 24 Bit
    • Signal-to-Noise Ratio (SNR): 100dB
    • Amplitude-Frequency Characteristic: ≤ ±0.5dB
    • Audio Input/Output Impedance: And 600Ω in equilibrium
    • Audio Maximum Input/Output Voltage: 0V - 4V/0V - 2.5V
    • Audio Gain: ±0.1dB
    • Maximum Input Level: ≥ 9.5dBm
    • Non-Linear Distortion: ≤ 0.2%
    • Audio Physical Interface:
      - Dual-on (Transmitter)
      - Cannon Head (Receiver)

      Physical
    • Working Temperature: -4°F - 158°F (-20°C - 70°C)
    • Storage Temperature: -40°F - 185°F (-40°C - 85°C)
    • Relative Humidity: 5% - 95% (non-condensing)
    • Working Life: > 100,000 hours

      Power Supply
    • Desktop Type: DC 12V/1A
    • Power Dissipation: < 2W
    • Rack Type: AC 110V - 240V, 50/60Hz

  • Item Includes:

    • 1x Thor Fiber F-4A-XLR-B-PHP Transmitter
    • 1x Thor Fiber F-4A-XLR-B-PHP Receiver
    • 2x US Power Cord

  • Warranty:

    • 5 Year Limited Warranty
