    ISA TWO - Overview

    Two Channels Of Classic Focusrite Mic Pres
    Focusrite's ISA Two brings together a totally independent pair of classic ISA microphone preamps from the original ISA 110 module, combining the best of traditional solid-state electronics with the original input transformer specified by Rupert Neve - the Lundahl LL1538.

    Each mic pre has the option of mic, line or the front-panel instrument input, with variable input impedance to ensure you are getting the best performance from the source. Up to 60dB of gain is available on the first four-position rotary and gain range switches, with a further +20dB of continuously variable trim, meaning a huge 80dB of gain is available should it be required. The high-pass filter features variable cut-off frequency between 16 and 420Hz. A pair of 8-segment LED meters show peak signal level in dBFS, while a rear-panel pot allows calibration to suit your A-D converters. Rear-panel insert points allow the use of inline processors such as compression.

    • Features:

      • Classic ISA mic preamp design featuring Lundahl LL1538 input transformer
      • Front-panel instrument inputs
      • Dedicated TRS line input socket with front-panel switch
      • Switchable input impedance including classic ISA 110 setting
      • Dedicated insert points
      • User-calibrated peak-level meters

    • Specifications:

      • Mic Input Response
      • Gain Range: 0dB - 60dB in 10dB steps, plus 0dB - 20dB continuously variable trim
      • EIN: Measured @ 60dB of gain with 150Ω source impedance and 22Hz - 22kHz band pass filter -127dB
      • Noise: Noise at output with unity gain (0dB) and 22Hz - 22kHz band pass filter -97dBu
      • Frequency Response: At minimum gain (0dB) -0.5dB @ 10Hz, -1dB @ 135kHz, relative to 1kHz
      • At 60dB Gain: -6dB @ 10Hz, -1dB @ 115kHz, relative to 1kHz
      • Crosstalk Channel To Channel: Mic input, with I/P = 0dBu, gain = 0dB @ 1kHz input to Channel A, Channel B output = -85dB

        Line Input Response
      • Gain Range: -20dB - 10dB in 10dB steps, plus 0dB - 20dB continuously variable trim
      • Input Impedance: 10kΩ from 10Hz - 200kHz
      • Frequency Response: At minimum gain (0dB) -0.3dB @ 10Hz, -1dB @ 80kHz, relative to 1kHz
      • Crosstalk Channel To Channel: Line input, with I/P = 0dBu, gain = 0dB @ 1kHz input to Channel A, Channel B output= -91dB

        Instrument Input Response
      • Gain Range: 10dB - 40dB continuously variable trim
      • Input Impedance: 2MΩ
      • Noise: Measured with 22Hz - 22kHz band pass filter, Minimum gain (10dB) = -95dBu
      • Frequency Response: At minimum gain (10dB)-0.1dB @ 10Hz, -1dB @ 115 kHz, relative to 1 kHz
      • At Maximum Gain (40 dB): -2.5dB @ 10Hz, -1dB @ 110kHz, relative to 1kHz

        High Pass Filter
      • Roll-Off: 18dB per octave (3 pole filter)
      • Frequency Range: Continuously variable from 16Hz - 420Hz (-3dB)

        Physical
      • Dimensions (HxWxD): 1.7" x 18.9" x 11"
      • Weight: 8.2lbs

    • Warranty:

      • 2 Year

    • GTIN:

      0815301005148
