Lilliput Q10 10.1 Inch HDMI 2.0 / 2x 12G-SDI 1500nits Ultra High Bright On-Camera 1920x1200 LCD Monitor

ITEM #: LIL-Q10 MFG #: Q10

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Lilliput Electronics
Free Shipping with $49 Minimum Order

List Price:

$1,199.00

Our Price:

$1,099.00

Add to Wish ListLeasing Options
Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup
    Report Lower PriceLarge Quantity Quote

    Q10 - Overview

    The Lilliput Q10 is a professional camera-top monitor with an amazing 1500 nit Ultra Bright LCD screen built specifically for photography and film makers. Designed for outdoor video and film shooting this 10.1 inch LCD monitor has 1920x1200 Full HD native resolution and 1200:1 high contast to provide superior picture quality, and to support 4K HDMI 2.0 and 12G-SDI signal inputs and loop outputs. It's possible to receive 2x 12G-SDI signals and display them at the same time using the picture-in-picture function with adjustable size and position. It accepts HDMI signals up to 4K 60Hz and is perfectly compatible with the latest DSLR cameras on the market that feature an HDMI 2.0 interface.

    • Features:

      • HDMI 2.0 input & loop output
      • 12G-SDI input & loop output
      • 1500 cd/m2 high Brightness
      • HDR (High Dynamic Range) supporting ST2084 300/ST 2084 1000/ST 2084 10000/HLG
      • 3D-Lut option of color production includes 17 default camera log and 6 user camera log
      • Gamma adjustments (1.8, 2.0, 2.2, 2.35, 2.4, 2.6, 2.8)
      • Color Temperature (5500K, 6500K, 7500K, 9300K, User)
      • Markers & Aspect Mat (Center Marker, Aspect Marker, Safety marker)
      • Scan (Aspect, Pixel To Pixel, Zoom)
      • Check Field (Red, Green, Blue, Mono)
      • Assistant (Peaking, False Color, Exposure, Histogram)
      • Image Flip (H, V, H/V)
      • 12G-SDI PIP, PBP functions
      • FN User-definable function buttons


    • Specifications:

      • Display
      • Panel: 10.1"
      • Physical Resolution: 1920x1200
      • Aspect Ratio: 16:10
      • Brightness: 1500 nit
      • Contrast: 1000:1
      • Viewing Angle: 170°/ 170°(H/V)
      • HDR: ST2084 300/1000/10000/HLG
      • Supported Log formats: SLog2 / SLog3 / CLog / NLog / ArriLog / JLog or User.
      • Look up table (LUT) support: 3D LUT (.cube format)

        Signal Input
      • SDI: 2x12G-SDI
      • HDMI: 1xHDMI 2.0
      • Tally: 1

        Signal Loop Output
      • SDI: 2x12G-SDI
      • HDMI: 1xHDMI 2.0

        Support Formats
      • SDI: 2160p 60/50/30/25/24, 1080p 60/50/30/25/24, 1080pSF 30/25/24,1080i 60/50, 720p 60/50.
      • HDMI: 2160p 60/50/30/25/24, 1080p 60/50/30/25/24, 1080i 60/50,720p 60/50.

        Audio In/Out
      • SDI: 16ch 48kHz 24-bit
      • HDMI: 8ch 24-bit
      • Ear Jack: 3.5mm
      • Built-in Speakers: 1

        Power
      • Input Voltage: DC 7-24V
      • Power Consumption: =37W (12V)

        Environment
      • Operating Temperature: 0°C~50°C
      • Storage Temperature: -20°C~60°C


    • Item Includes:

      • 1x Q10 12G-SDI 1500nits Ultra High Bright On-Camera LCD Monitor


    • Warranty:

      • Limited 1-Year Warranty


    • GTIN:

      6950821602508
