Marshall CV502-WPMB Mini Broadcast IP67 Weatherproof Camera 2MP 59.94/29.97fps - CV502 in IP67 Housing
  • Marshall CV502-WPMB Mini Broadcast IP67 Weatherproof Camera 2MP 59.94/29.97fps - CV502 in IP67 Housing
  • Marshall CV502-WPMB Mini Broadcast IP67 Weatherproof Camera 2MP 59.94/29.97fps - CV502 in IP67 Housing
  • Marshall CV502-WPMB Mini Broadcast IP67 Weatherproof Camera 2MP 59.94/29.97fps - CV502 in IP67 Housing
  • Marshall CV502-WPMB Mini Broadcast IP67 Weatherproof Camera 2MP 59.94/29.97fps - CV502 in IP67 Housing
  • Marshall CV502-WPMB Mini Broadcast IP67 Weatherproof Camera 2MP 59.94/29.97fps - CV502 in IP67 Housing


Marshall CV502-WPMB Mini Broadcast IP67 Weatherproof Camera 2MP 59.94/29.97fps - CV502 in IP67 Housing

Manufacturer: Marshall Electronics

Item #: MAR-CV502-WPMB   •   MFG #: CV502-WPMB



This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

800-522-2025Email





Item unavailable. Please select another option.

Items similar to the MAR-CV502-WPMB

California Residents:
8pt-triangleWARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov





Marshall Electronics incorporated everything the CV502-MB/M camera delivers and built a weatherproof IP67 rated (protected against effect of immersion between 15cm - 1m) housing around it - CV502-WPMB/WPM. Perfect for applications where weather becomes a factor like outdoor sporting events, nature observation, weather coverage, news coverage, reality TV, mobile broadcast, or any outdoor application where mother nature has an influence. Utilizing new state of the art 1/3-inch high speed sensor packing 2,476,296 pixels (2.5 Megapixels) of clear, crisp video capture through full sized 3G/HD-SDI (BNC) outputs at resolutions of 1920x1080i, 1920x1080p, 1280x720p & frame-rates of 60/59.94/50/30/29.97/25 fps. New proprietary pixel technology offers the lowest noise ratio on the market today capturing sharp, vivid color images in very low light conditions, as low as 0.05 lux. Industry leading low power consumption draws very low power in full 1920x1080p60/59.94/50fps modes. New weatherproof CV502-WPMB/WPM Pro-Series POV Cameras continue to offer Field-of-View flexibility with interchangeable lenses and convenience of HD-SDI outputs maintaining a broadcast standard for POV camera applications. New RS485 connect-ability offers remote camera control communication via SONY VISCA or PELCO protocols.

Power supply is included.

CV502-WPMB/WPM Applications:
Broadcast Television
Professional Sports
College Sports
OB Vans/Trucks
Concert & Studio Music Video
Reality TV
Performing Arts
Culinary Shows
Car TV Shows
Hidden Camera Shows
International Racing Circuits
Off-road Racing
Horse Racing
House of Worship
POV Video Shots.


  • Features

    • 2.5 Megapixel 1/3-inch CMOS Sensor
    • Weatherproof IP67 rated Housing for outdoor applications
    • IP67: total protection against dust, dirt, sand - protected against effect of immersion between 15cm - 1m
    • CV502-WPMB:1920x1080p59.94/29.97, 1920x1080i59.94, 1280x720p59.94/29.97fps
    • CV502-WPM: 1920x1080p60/50/30/25, 1920x1080i60/50, 1280x720p60/50/30/25fps
    • 3.7mm HD M12 Lens comes standard - 2.8mm (CV4702.8-3MP-IR) & 6.0mm (CV4706-3MP-IR) also available
    • 3G/HDSDI (BNC) & CVBS (BNC) connections at end of 10' breakout cable
    • RS-485 (connector) & 12V Power (connector) at end of 10' breakout cable
    • Captures sharp & vivid color HD images at 0.2Lux (low light sensitive)
    • New WDR function supports high speed & high sensitivity to multiple light sources
    • Stepped (Red/Blue) Gain Control, Gamma, Brightness, and Shutter adjust via RS485 (Visca/Pelco)
    • OSD Menu Joystick, RS-485 connectable(Pelco/Visca)
    • Free Downloadable Software Control

    • Compatible M12 Lens options for weatherproof CV502-WPMB/WPM
    • CV4702.8-3MP-IR 2.8mm F2.0 M12 Lens with IR Filter
    • CV4706-3MP-IR 6.0mm F2.0 M12 Lens with IR Filter

    • Applications
    • Broadcast Television
    • Professional Sports
    • College Sports
    • OB Vans/Trucks
    • Concert & Studio Music Video
    • Reality TV
    • Performing Arts
    • Culinary Shows
    • Car TV Shows
    • Hidden Camera Shows
    • International Racing Circuits
    • Off-road Racing
    • Horse Racing
    • House of Worship
    • POV Video Shots

  • Specifications

    • Sensor
    • Image Sensor: 1/3" Progressive CMOS (Approx. 2.1 mega)
    • Scanning System: 16:9 Progressive
    • Sync. System: Internal
    • Effective Pixel: 1920(H) x 1080(V)
    • Min. Illumination: 0.2 Lux (Color), 0.1 Lux (Black/White), 0.005 Lux(DSS on)
    • Horizontal Resolution: 1000TVL

    • Optics
    • Lens: CV502 comes with 3.7mm (M12 mount) - interchangeable

    • Functions
    • Back Light Compensation: WDR (Wide Dynamic Range)/BLC (Back Light Compensation), HLC (High Light Compensation)
    • Exposure: Auto / Manual
    • White Balance: Auto (3,000°K~8,000°K) / ATW (1,900°K~11,000°K) / Manual
    • Day & Night System: AGC (Automatic Gain Control) / True Day/Night auto switch based on light environment (auto/manual) (ICR)
    • Electronic Shutter: NTSC: 1/30~1/30000, PAL: 1/25~1/30000, DSS( ~X64)
    • Functions: Privacy Mask, Image Mirror, 3DNR, Flicker-less, Sharpness, Defog, DIS (Digital Image stabilizer), NegArt, Freeze, B&W

    • Video Outputs
    • 3G-SDI (+optional Audio) and HD-SDI (+optional Audio)
    • -SMPTE 424M(2.97Gbps):
    • 1920x1080p @ 59.94fps (-MB/-CSB) or
    • 1920x1080p @ 50/60fps (-M/-CS)
    • -SMPTE 292M(1.485Gbps):
    • 1920x1080p @ 29.97 (-MB/-CSB) or 25/30 (-M/-CS)
    • 1920x1080i @ 59.94 (-MB/-CSB) or 50/60fps (-M/-CS)
    • 1280x720p @ 59.94/29.97fps (-MB/CSB) or 50/60 (-M/-CS)
    • CVBS (BNC): Composite-CVBS (BNC): 700TVL NTSC/PAL

    • Audio Input
    • MIC Input: Mic Level (1Vrms). 2.5V Mic bias
    • 16, 20, 24, 32 bits audio format. 48KHz sample rates
    • Gain: -12dB ~ 59.5dB

    • Control Interface: RS-485
    • PELCO-P/D, SONY-VISCA protocol
    • 8 bits data, 1 stop bit, no parity, 2400~115200bps

    • General
    • Operation Temperature: -10°C ~ 50°C
    • Power Input: 12VDC (7V to 15VDC)
    • Power consumption: Max 6W
    • Dimensions: 37(W) X 37(H) X 35(D)mm
    • Weight (Net): Approx. 140g

  • GTIN:

    0801813180893
