500709-TX - Overview

The MuxLab 500709-TX HDMI 2.0 over MM FiberTransmitter works with the 500709-RX Receiver (sold separately) .It's a versatile solution for extending video and audio transmission over long distances. The pair can extend video and audio transmission distance up to 300m (990ft) (OM3) / 400m (1320ft) (OM4) over fiber and supports Ultra-HD 4K2K@60(4:4:4) format, providing high-quality visuals.

This HDMI 2.0 fiber extender is a comprehensive solution for demanding applications that require reliable, high-quality Ultra-HD video broadcasting over fiber, with added features such as RS-232 pass-through and video wall support.

Applications
Medical Imaging
Military Control Rooms
Broadcast Control Rooms
Restaurants
Conference Centers

  • Features:

    • Supports HDMI resolutions up to 4K/60 (4:4:4)
    • Uncompressed up to 4K/60 (4:2:0), and light compression visually lossless at (4:4:4) (with zero latency)
    • Extends the transmission over multi-mode optical cable up to 300m (990ft)(OM3)/400m (1320ft)(OM4)
    • Full duplex RS-232 control up to 115,200 bps


  • Specifications:

    • HDMI Compliance: HDMI 2.0a
    • HDCP: HDCP 2.2 and 1.4
    • Video Bandwidth: Single Link 594MHz (18Gbps)
    • Video Support: 480i/480p/720p/1080i/1080p60/4K30/4K60 4:4:4
    • Audio Support: Surround sound (up to 7.1ch) or stereo digital audio
    • RS232 Support: 3-Pin Terminal Block Connector
    • HDMI Connection: 1x HDMI input
    • Housing: Black Metal enclosure
    • Working Power Supply: 12VDC, 2A
    • Weight: 7.87oz (223g)
    • Working Temperatyre: 32°F - 104°F (0°C - 40°C)
    • Dimensions: 3.5" x 3.54" x 0.98" (89mm x 80mm x 25mm)


  • Item Includes:

    • 1x 500709-TX HDMI 2.0 Over Multi-Mode Fiber Transmitter only


  • Warranty:

    • 2 Year Warranty


  • GTIN:

    0627699907092
