Mystery Electronics TC20 Self Trimming Satin Black Floor Box with Cable Slots

ITEM #: MYS-TC20 MFG #: TC20

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:


Our Price:


Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup

    TC20 - Overview

    The TC20 raised access floor box combine fl exibility, ease of installation, high capacity, and long-term value in an economical floor box assembly. Proprietary modular panel design accommodates a wide variety of AV connectors, active devices, as well as Neutrik PowerConn series connectors. The concrete rated rough-in box includes alignment labeling and detailed installation instructions for rough-in installation above grade. Unique design and 12 gauge cover supports loads in excess of the 300lb UL standard. Ideal for classrooms, houses of worship, conference rooms, courtrooms,performance venues or anywhere connections are needed in the floor. The attractive design and finish allows for the TC20 to also be used for in-wall applications.

    • Features:

      • Attractive satin black 12 gauge scratch resistant cover with powder coated finish
      • Accepts all DuoLine Insert Panels (up to 2ea XLR type connectors, active devices or Neutrik PowerConn)
      • Cable Slots allow cables up to 1/4" O.D.
      • Self-trimming cover installs on top of carpet or hard surface
      • Perfect for mounting in a stair riser or floor applications
      • Options include:
      • Pre-punched insert panels
      • Rough-in box
      • Connector loading
      • Labeling and more
    • Specifications:

      • Door/Cover: 11.75"L x 5"W
      • Basket: 9.25"L x 2.5"W x 2.5"D
      • (without rough-in box)
    • Item Includes:

      • Cover
      • Gasket
      • Basket
      • Mounting Hardware

    TC20 - Required Accessories
