Neutrik NC6MX Male 6-Pin XLR Cable Connector

ITEM #: NC6MX MFG #: NC6MX

free ship

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$6.80

Our Price:

$5.83

Availability: In Stock
iAvailability Description Popup


    NC6MX - Overview

    The Industry Standard XLR cable connector, easy to assemble with only 4 parts and no screws. Compact design with sturdy diecast shell, fibreglass reinforced hard plastic insert and chuck type strain relief for secure clamping of all cables.

    • Features:

      • Rugged zinc diecast shell, long lasting and durable
      • Chuck type strain relief system for secure clamping of cables
      • Boot with rubber gland gives high protection against bending stresses
      • Coloured rings and boots available for coding and marking
      • UL recognized components

    • Specifications:

      • Connection Type; XLR
      • Gender: female
      • Capacitance between contacts: ≤ 7 pF
      • Contact resistance: ≤ 3 mΩ (inner)
      • Dielectric strength:1,5 kVdc
      • Insulation resistance: > 2 GΩ (initial)
      • Rated current per contact: 7,5 A
      • Rated voltage: 50 V
      • Cabel O.D: 3.5 - 8.0 mm
      • Insertion force: ≤ 20 N
      • Withdrawal force: ≤ 20 N
      • Lifetime: > 1000 mating cycles
      • Wiresize: max. 1.0 mm²
      • Wiresize: max. 18 AWG
      • Wiring:Solder contacts
      • Locking device; Latch lock
      • Boot:Polyuretan
      • Bushing:Polyamide (PA 6 15% GR)
      • Contact plating:2 µm Ag over 2 µm Ni
      • Contactsl:Brass (CuZn39Pb3)
      • Insert:Polyamide (PA 6.6 30 % GR)
      • Shell:Zinc diecast (ZnAl4Cu1)
      • Shell plating: Nickel
      • Strain relief: Polyacetal (POM)

    • GTIN:

      7613187003547
