Ashly Audio NE24.24M 12X8 LOGIC Protea 12x8 DSP Audio Matrix Processor with Logic Card

ITEM #: NE24-24M12X8LOGI MFG #: NE24.24M 12X8 LOGIC

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:


Our Price:


Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup

    NE24.24M 12X8 LOGIC - Overview

    The Ashly NE24.24M 12X8 LOGIC uses modular expansion cards to provide up to 24-channels of audio matrixing and processing. Prot?a ne24.24M's base unit offers a 4-input/4-output configuration. Each input and output expansion card has an individual DSP processor allowing you to expand the total input or output 4 channels of DSP processing at a time. Matrixing allows you to route any input to any output and control individual levels once they have been assigned. An optional GPO Logic Card allows the ne24.24M to trigger projection screens, curtains or lights.

    • Features:

      • 10/100 Ethernet & RS-232 computer interface standard
      • Extensive DSP available via Protea DSP
      • Easy and intuitive user interface
      • Control with free Ashly Remote iOS App Mic/line inputs
      • 24-bit A/D - D/A audio resolution
      • Up to 24-channels of audio processing
      • 4×4 base unit configuration
      • Expand inputs or outputs 4-channels per module
      • Modules easily field installable
      • Euroblock connectors for audio, preset recall, DC remote level control and data in/out
      • 31 preset locations
      • Remote controls for level, preset recall and programmable functions
      • Third-party control-friendly
      • Input and output metering viewable in dBu
      • Multi-level security
      • Safety/Compliance: cTUVus,FCC, CE, RoHS
    • Specifications:

      • Input: Active Balanced, 18k Ohms
      • Input Gain Range: -50dB - +12dB, Selectable Polarity
      • Output: Active Servo Balanced, 112 Ohms
      • Input/Output Level: +20dBu (Max)
      • Output Gain Range: -50dB - +12dB, Selectable Polarity
      • Frequency Response: 20Hz - 20kHz, ±0.25 dB
      • THD: <0.01 % @ 1kHz, +20 dBu
      • Dynamic Range: >110dB (20Hz - 20kHz) Unweighted
      • Output Noise: <-90 dBu Unweighted
      • Environmental: 40 to 120F, (4 to 49C) noncondensing
      • Controls: Remote level control, Data In/Out ports, Preset Recall, Logic Inputs, On/Off switch
      • Connections: 10/100 Ethernet port, RS-232, Euroblock In/Out
      • Power Cord: 3-Prong, Detachable
      • Weight, Dimensions & Power:
      • Dimensions: 19L x 3.5H x 8.5D in / Unit Weight: 8.9lbs (4.04kg)
      • Shipping Weight: 12lbs (6kg)
      • Power Requirements: 90 - 240VAC, 50/60Hz, 40W
