Netgear AV Line M4350-8M2V 8x2.5G PoE++ and 2x25G SFP28 Fully Managed Switch - 119W Base/551W Max

MSM4310-100NES - Overview

AV Over IP Simplified

• Features:

  • 8x 2.5G PoE++ ports with 2x 25GBASE-X SFP28 uplinks.
  • Comes with one APS254W power adapter providing 119W of base PoE budget.
  • Half-width form factor enables one or two switches in a single rack space
  • Up to three APS254W power adapters provide up to 551W PoE budget and/or N+1 redundancy
  • The PoE budget can reach 551W, when the redundant PoE budget is 119W (1+1) or 322W (2+1).
  • Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover.
  • Layer 3 feature set includes static, policy-based, and dynamic routing.
  • NETGEAR IGMP Plus, NETGEAR AV OS, and Engage Controller speed up AV installations.
  • SMPTE ST 2110 Grand Master Clock and Boundary Clock for AES67 and ST2059-2 applications.
  • Multi-color LED on each physical port reflecting the profile color in the NETGEAR AV OS and Engage Controller.


• Specifications:

  • Width: 8.67" (220mm)
  • Depth: 11.81" (300mm)
  • Height: 1.7" (43.2mm)
  • Weight: 6.39lbs (2.9kg)
  • Primary Port Speed: 2.5 Gigabit
  • Number of Ports: 10 (8x 2.5G PoE++, 2x 25G SFP28)
  • Total PoE++ Ports: 8
  • Total PoE++ Budget: 119W Base, up to 551W
  • IGMP Support: Enhanced (NETGEAR IGMP PlusT)
  • Jumbo Frame Support: Yes, up to 12kb
  • AVB Support: Yes, included
  • Acoustics: Quiet Mode 32.1dB@77°F
  • Power Consumption:
    - With max PoE: 682W/2,324.93Btu/hr
    - Without PoE: 82W/27.95Btu/hr
    - Standby without any port connection: 61.2W/208.6Btu/hr


• Item Includes:

  • 1x M4350-8M2V Fully Managed Switch
  • 1x Power Cord
  • 1x Console USB Type-C Cable
  • 1x Rack-Mounting Standard Bracket Set
  • 1x Set of Longer Brackets for Recessed Mounting
  • 1x Rubber Footpads for Tabletop Installation
  • 1x Installation Guide


• Warranty:

  • Limited Lifetime Warranty
