OCC D-SERIES D-002CALT OM3 2-Fiber Mil-Tac 50 Micron Tight-Buffer Multimode Ground-Tactical Cable - Per Foot

D-002CALT-FT - Overview

• Features:

  • Extremely strong, lightweight, rugged, survivable tight-buffered cables designed for military tactical field use and commercial applications
  • Compact, round cable design for ease of transportation and deployment
  • Core-locked® jacket for improved mechanical performance Designed for use in adverse environments where reduced size and weight are important
  • Helically stranded cable core for flexibility, deployment survivability and exceptional mechanical protection for the optical fibers
  • Cables have been tested and are in use in military data communications applications worldwide
  • Can be used outdoors for temporary deployment directly on the ground in all terrains, including severe environments
  • Suitable for industrial, mining and petrochemical environments - chemical resistant
  • Crush-resistant and resilient with a thick layer of aramid strength members
  • Polyurethane jacketed for abrasion, cut and chemical resistance Most commonly used with ruggedized multiway military tactical field connectors, for maximum connector retention (400lbs)
  • Tactical Polyurethane (C) outer jacket material is standard; Flame-Retardant Tactical (V) and Low-Smoke Zero-Halogen (G) outer jacket materials are available
  • Ultra-Fox Plus Fiber (500µm) used for environmental and mechanical protection


• Specifications:

  • Length: Per foot
  • Fiber Count: 2
  • Diameter: 0.20" (5.0mm)
  • Weight (1000ft): 14lbs (21.0kg)
  • Operating Temp: -67°F - 185°:F (-55°C - 85°C)
  • Storage Temp: -94°F - 185°F (-70°C - 85°C)
  • Crush Resist: 1800 N/cm
  • Impact Resist: 1500 impacts
  • Flex Resist: 2000 cycles
