Chauvet onAir Panel 3 IP IP65 Indoor/Outdoor Full-spectrum Low-profile 1x3 Format LED Soft Light

ONAIRPANEL3IP - Overview

• Features:

  • Full-spectrum LED linear format soft light panel style fixture for broadcast, film, and special events
  • IP65 rating for all weather use indoors or out
  • Linear color temperature presets from 2800K to 8000K with high CRI and CQS
  • Virtual color wheel with color matched to popular gel colors
  • +/- Green adjustment and emulated red-shift via DMX or on-board control
  • RDM (Remote Device Management) and CRMX Wireless Control for added flexibility
  • Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
  • Virtually silent operation for use in studio applications
  • Ultra-smooth 16-bit dimming curves and speeds to complement any lighting scheme
  • Easily switch mounting options from jr pin to omega bracket
  • Drop-in slot for diffusers and intensifier filter (sold separately)
  • Rugged design for years of rough use in the most extreme conditions
  • Easy to use on-board control with full access to all the features of the fixture without the need for a dedicated controller
  • USB port for fixture software updates
  • 28VDC power input via 3-pin XLR to power the fixture from an external battery pack


• Specifications:

  • Power Connection: Edison (Local) plug to Seetronic Powercon IP65
  • Power Input: Seetronic Powercon IP65
  • Power Output: Seetronic Powercon IP65
  • Power Input: 28VDC, 3-pin IP65 XLR
  • Data Connectors: 5-pin IP65 XLR, Seetronic etherCON Compatible
  • Cable Length (power): 5ft (1.5m)
  • Software Connection: Type-C USB
  • Control Protocol: Art-Net, sACN, DMX, WDMX, CRMX, RDM
  • DMX Channels: 1, 3, 4, 5, 6, 8, 11, 12, 15, 19, 24, XY Basic, XY Extended
  • Art-Net Channels: 1, 3, 4, 5, 6, 8, 11, 12, 15, 19, 24, XY Basic, XY Extended
  • Modes/Personalities: 14 personalities (1, 3, 4, 5, 6, 8, 11, 12, 15, 19, 24, XY Basic, XY Extended)
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Strobe Rate: 0Hz - 20Hz
  • Standalone Color Mixing: Yes
  • Color Temperature Presets: Yes
  • Dim Modes: 4
  • Dim Curves: 4
  • Built-in Automated Programs: Yes
  • Input Voltage: 100V - 240VAC, 50/60Hz (auto-ranging)
  • Power Linking: 8 units @ 120V; 14 units @ 208V; 16 units @ 230V
  • Power and Current: 167W, 1.392A @ 120V, 60Hz
  • Power and Current: 160W, 0.823A @ 208V, 60Hz
  • Power and Current: 157W, 0.747A @ 230V, 50Hz
  • IP Rating: IP65, temporary outdoor use, with pressure equalizing M12 GORE valve
  • Temperature (Ambient): -13°F - 113°F (-20°C - 45°C)
  • Light Source: 120 LEDs (tri-color RGB) 1.5W, (282mA), 50,000 hours life expectancy
  • Light Source: 120 LEDs (WW) 0.5W, (113mA), 50,000 hours life expectancy
  • Color Temperature (range): 2800K - 8000K
  • Color Temperature (at full): 5527K
  • CRI (3200K): 91.2
  • Beam Angle (No Optics): 111.3°
  • Beam Angle (Light Filter): 96.7°
  • Beam Angle (Medium Filter): 97.8°
  • Beam Angle (Heavy Filter): 108.2°
  • Beam Angle (Intensifier Filter): 74.4°
  • Selectable PWM: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 25,000Hz


• Item Includes:

  • 1x onAir Panel 3 Slim IP
  • 1x Seetronic Powercon IP65 power cord
  • 1x Omega bracket with mounting hardware pack
  • 1x onAir Panel 3 IP Medium Diffusion Filter
  • 1x TV Junior Spigot
