IP Network Traffic Measurement
Phabrix PHQXO-IP-MEAS is an advanced engineering suite of tools for ST 2110 analysis and debug offers the provision of up to four simultaneous dual Packet Interval Timing measurement windows per input for easy visualization of network congestion and sender packet distribution with max, mean and min inter-packet arrival times. Also included is detailed data reporting of flow packet, clock rates and PTP timing relationship, as well as the measurements of the ST 2110-21 Network Compatibility model (CINST) and Virtual Receiver Buffer Model (VRX). Advanced measurement of IP flow latency and RTP clock timing relationships for debug of Audio, Video and ANC alignment, source PTP and encapsulation are featured.
When your system includes the PHQXO-IP-MEAS license, the Video Timing & System Reference window includes the following three tabs, providing access to different timing data:
-External Reference vs PTP
