PreSonus AudioBox iOne 2x2 USB 2.0 iPad Recording Interface with 1 Mic Input

ITEM #: PRE-AUDIOBOXI1 MFG #: AUDIOBOX IONE

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the PRE-AUDIOBOXI1

AUDIOBOX IONE - Overview

Excellent choices for mobile musicians, sound designers, and podcasters, the USB 2.0 bus-powered AudioBox iOne and iTwo provide high-quality audio I/O for Mac, PC, and Apple iPad. These compact, ruggedly built interfaces offer high-performance Class A mic preamplifiers, record 24-bit audio at up to 96 kHz, and include powerful, easy-to-use Studio One Artist DAW for Mac and Windows and Capture Duo recording software for iPad.

StudioOne Artist lets you Focus on Your Music.
Like all PreSonus interfaces and digital mixers, the AudioBox iOne and iTwo come with our award-winning, all-muscle, no-bloat Studio Oner Artist recording and production software for Macr and Windowsr. Studio One is incredibly easy to use thanks to its clear, straightforward, single-window design and powerful file browser with extensive use of drag-and-drop. As a result, you can record your inspirations quickly, without getting distracted by the tools. Tasks that would require multiple steps in other DAWs can be done in just one or two steps with Studio One.

AudioBox iOne and iTwo are mobile interfaces in the best sense of the term. They can sit on a tabletop or fit in the pocket of a backpack or laptop bag and are powered by the USB bus, so you don't have to mess with a "wall wart" power supply or AC cord. And they're built to withstand the rigors of travel.

Class A All the Way.
PreSonus' award-winning analog signal processors and microphone preamps have long been popular among top professionals and home enthusiasts alike. So when you see the name PreSonus, you expect top audio quality-and the AudioBox i series delivers.

In addition, Studio One Artist includes a wealth of professional-quality plug-ins, virtual instruments, sounds, and loops. If you want even more, there's a low-cost upgrade path to Studio One Producer and Professional.

  • Features:

    • Bus-powered USB 2.0/iPad audio interface
    • 24-bit resolution; 44.1, 48, 88.2, and 96 kHz sampling rate
    • 1 microphone input with low-noise, high-headroom, Class A mic preamplifier and +48V phantom power
    • 1 instrument input
    • 2 balanced 1/4" TRS main line-level outputs
    • Stereo headphone output with independent level control
    • Zero-latency monitoring via internal analog mixer (iOne: fixed 50/50 mix via Direct button; iTwo: variable mix via Mix knob)
    • Large main volume knob
    • Signal present and clipping LEDs
    • Studio One Artist DAW software (Mac/Windows) and 6+ GB of third-party resources
    • Transfer files wirelessly from Capture for iPad to Studio One
    • Compatible with almost all recording software for Mac, Windows, and iPad
    • Nimbit Free account to distribute and sell your music
    • Kensington lock hole
    • Metal chassis

  • Specifications:

    • Microphone Preamp
    • Type: XLR female
    • Frequency Response: (±3.0 dB) 10 Hz to 40 kHz
    • Input Impedance (Balanced): 1,200 ohm
    • THD+N (unwtd, 1 kHz @ +4 dBu Output, Unity Gain): < 0.008%
    • S/N Ratio (Unity Gain, Ref. = +4 dBu, 20 Hz to 22 kHz): > 95 dB
    • Common Mode Rejection Ratio (1 kHz, 52 dB Gain): > 65 dB
    • Gain Control Range (± 1 dB): 0 dB to 52 dB
    • Max Input Level (Unity Gain, 1 kHz @ 0.5% THD+N): +10 dBu
    • Phantom Power (±2 VDC) +48 VDC

      Instrument Input
    • Type: 1/4" TS female, unbalanced
    • Input Impedance: 1 MO

      Line Outputs
    • Type: 1/4" TRS female, balanced
    • Output Impedance: 51O
    • Output Level: +10dBu

      Headphone Output
    • Type: 1/4" TRS active stereo
    • Maximum Output: 60 mW/ch. @ 60O Load
    • Frequency Response: (±1.0 dB) 20 Hz - 30 kHz

      Digital Audio
    • ADC Dynamic Range (A-wtd, 48 kHz Sample Rate): 105 dB
    • DAC Dynamic Range (A-wtd, 48 kHz Sample Rate): 105 dB
    • Bit Depth: 24
    • Reference Level for 0 dBFS +10 dBu
    • Internal Sample Frequency Selections (kHz): 44.1, 48, 88.2, 96
    • Power: USB bus-powered

      Physical
    • Height: 1.71" (43.5 mm)
    • Depth: 5.31" (135 mm)
    • Width: 5.91" (150 mm)
    • Weight: 1.35 lbs (0.62 kg)

  • Computer System Requirements

    :

    • Windows 7 x64/x86 SP1, Windows 8 x64/x86 or later
    • Intel Core Duo processor (Intel Core i3 or better recommended)
    • 4 GB RAM (8 GB or more recommended)
    • Mac OS X 10.8 or later
    • Intel CoreT Duo processor (Intel Core i3 or better recommended)
    • 4 GB RAM (8 GB or more recommended)
    • Windows and Mac Systems:
    • USB 2.0 Port
    • Internet connection for registration and download of included software
    • Internal or external 7200 RPM storage drive highly recommended
    • Monitor with at least 1280x800 resolution
    • Apple iPad
    • iPad Air, iPad mini with Retina display, iPad (4th generation), iPad mini, iPad (3rd generation), iPad 2
    • iOS 7.0.1 or higher

  • GTIN:

    0673454002922
