Fiberplex PSQ-2909 Easy-On Power Supply for Size 2 FOI Type Isolator Stand-Clone Configuration - 100-240 VAC 50/60 Hz

ITEM #: PSQ-2909 MFG #: PSQ-2909

free ship

Our Price:


Availability: Extended Lead Time. Email, Chat or Call Us for more details.
iAvailability Description Popup

    PSQ-2909 - Overview

    The FiberPlex PSQ-2909 PSQ-3909 is compact AC power supplies which attach to and provide operating voltage for FiberPlex Technologies FOI series isolators.

    The RFI suppressed ‘R' variant of this power supply has been tested and is recommended for high security or TEMPEST applications.

    The FiberPlex PSQ supply has been updated to be easier to assemble. Previous versions of the PSQ required a separate bracket and multi-step process to attach the supply to an FOI. This new design you just pop on the back of the FOI and tighten two thumb screws. The all enclosed design will also meet the most stringent safety standards.

    For more rugged mounting, wall mount adapters, WMA-2001 and WMA-3002, are available to secure the power supply and fiber optic isolator with screws. Both WMA-2001 and WMA-3002 are compatible with all PSQ and FOI series. The WMA-2001 has an optical patch while the WMA-3002 does not. The wall mount adapter attaches to either a horizontal or vertical flat surface and provides a convenient termination point which protects both the fiber optic cable and the fiber optic isolator from damage.

    • Features:

      • 9 VDC, 9 Watt power supplies for FOI Isolators
      • Easy, bracket free attachment
    • Specifications:

      • Input Voltage: 100 - 240 VAC
      • Input Frequency: 50 - 60Hz
      • Output Voltage: 9 VDC
      • Supply Current: 1A
      • Output Power: 9W
      • Storage Temperature: -40°F - 185°F (-40 - 85 °C)
      • Operating Temperature: -13°F - 122°F (-25° - 50°C)

    PSQ-2909 - Required Accessories

      PSQ-2909 - Recommended Accessories
