AIDA Imaging PTZ412G-FNDI-X30W 30x Zoom 4K NDI HX3 12G-SDI & SFP+ Auto-Tracking Broadcast/Conference PTZ Camera - White

PTZ4K12GFNDI-X30W - Overview

• Features:

  • The camera utilizes a 4K 9MP UHD Sony CMOS sensor, for enhanced digital imaging beyond, color capture, and realism
  • Its workhorse reliability allows you to simultaneously stream out all sources at once
  • Control via IR remote, Web UI, or HTTP access for full control over the PTZ
  • Beefy design for heating, aesthetics, and durability
  • Full Tally Mohawk for talent recognition, and easier broadcast queuing. Automatically controlled via NDI.
  • Genlock capable PTZ for no-lag ultrasynced productions where timing is crucial
  • SFP+ Fiber port for even more added value to match production needs
  • Take in audio over the 3.5mm line in input, or Mini XLR for versatile audio/video embedment needs
  • Capture realism through the virtual world using our FreeD protocol, over all outputs (only supported via 12G-SDI)
  • Automatically track targets with ease using our AI-based Autotrack feature


• Specifications:

  • Image Sensor: 1/1.8" Progressive Sony CMOS
  • S/N Ratio: =50dB
  • Resolution: 2160p, 1080p, 1080i, 720p
  • Outputs: 12G-SDI, 3G-SDI, HDMI, USB, SFP+ slot, RJ45 (NDIr, IP, SRT)
  • Min Illumination: 0.5Lux (50 IRE Max AGC,1/30, F1.8)
  • White Balance: Auto/Manual/AT/Push/Indoor/Outdoor/Color Temp/Shutter Priority/Iris Priority Brightness Priority
  • Pan Rotation Angle: -170° - + 170°
  • Tilt Rotation Angle: -90° - + 90°
  • Pan Rotation Speed: 0.1° - + 80°
  • Tilt Rotation Angle: 0.1° - + 60°

    Lens Module
  • Module: 30X UHD Optical Zoom
  • Lens: f=6.91mm - 214.64mm
  • F-stop: F1.35 - F4.6
  • H-FOV: 60° (wide) - 2° (tele)
  • Min. Focus Dist: 5ft (tele/wide)

    Standard
  • IP Protocols: UDP/TCP/IP/ONVIF/PELCO/VISCA/VISCAOVERIP/SRT/RTSP/RTMP/NDI/HTTP
  • Audio Input: 3.5mm line level input, Mini-XLR with 48V phantom Power)

    Physical
  • Camera Control Protocol: VISCA Over IP, VISCA, ONVIF, NDIr
  • Operation Temp: 32°F - 104°F
  • Dimension: 10.5" x 9" x 12" (when module is straight up)
  • Weight: 10.12lbs (4.59kg)
  • Power:12VDC (+9V - +15VDC), PoE++ Standard (802.3bt)

    Camera Streaming Modes (all outputs still simultaneous)
  • ROI Priority: Prioritizes 12G-SDI/HDMI/USB outputs
  • NDI High Bandwidth Mode: Prioritizes HB NDI/NDI HX(3) to
  • run simultaneously.


• Item Includes:

  • 1x Remote Controller
  • 1x USB-C Cable
  • 1x Power Adapter & Cable
  • 1x Mini XLR to XLR
  • 1x RS232 Cable
