PTZCam PTZC-IPPRO30 HD Auto-Tracking PTZ Camera with NDI / SDI / HDMI / USB Outputs and 30x Optical Zoom

ITEM #: PTZC-IPPRO30 MFG #: PTZC-IPPRO30

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$779.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


PTZC-IPPRO30 - Overview

The PTZCam PTZC-IPPRO30 is a cutting-edge PTZ camera designed to take your HD broadcasting to unparalleled heights. Whether you're in a television studio, church, school, concert venue, or any setting that demands superior video quality, this camera delivers exceptional performance at an unbeatable price.

With a powerful 30x optical zoom, the IP Pro 30 excels at capturing crystal-clear, detailed footage in medium to large-sized rooms. Its versatility is unmatched, offering a wide array of output options including 3G-SDI, HDMI, and USB. For seamless video transmission over networks, the camera features a built-in H.264/H.265 streaming encoder supporting up to 1080p60 in formats such as NDI|HX2, RTMP, RTSP, SRT, and ONVIF.

What sets the IP Pro 30 apart is its integrated AI-driven auto-tracking and framing capabilities. While traditional PTZ methods allow for manual control, the auto-tracking feature intelligently follows human subjects, ensuring they remain smoothly and naturally within the frame without user intervention. This game-changing technology simplifies the setup for lectures, sermons, or presentations-just a few clicks and the camera takes care of the rest.

The IP Pro 30 combines advanced technology, user-friendly operation, and affordability, making it the ultimate choice for your broadcasting needs.

  • Features:

    • NDI|X2 output, plus RTMP, RTSP, SRT, and ONVIF
    • AI auto-tracking and framing
    • 30x optical zoom
    • 2.07 megapixel, SONY 1/2.8" CMOS sensor
    • 3G-SDI and HDMI output up to 1080p60
    • USB 3.0 output over UVC 1.1 protocol up to 1080p60 (YUY2, MJPEG compression)
    • PoE+ power input compatible

  • Specifications:

      Image Parameters
    • Resolution:
      - HDMI: 1080p: 60/59.94/50/30/29.97/25, 1080i: 60/59.94/50, 720p: 60/50
      - SDI: 1080p: 60/59.94/50/30/29.97/25, 1080i: 60/59.94/50, 720p: 60/50
    • Image Sensor: SONY 1/2.8" CMOS
    • Pixels: 3.10 Megapixels, 2.07 Effective Megapixels
    • Scan Mode: Line by line
    • Lens: 30x Optical Zoom, f=5.2m (W) - 156mm (T)
    • Horizontal View Angle: 58.1° (W) - 2.14° (T)
    • Vertical View Angle: 34.1° (W) - 1.2° (T)
    • Focus System: Auto, Manual
    • Shutter Speed: 1/50s - 1/10000s
    • Minimum Illumination: 0.1 Lux @ (F1.5, AGC ON)
    • Exposure: Auto, Manual, Iris Priority, Shutter Priority, Brightness priority
    • White Balance: Auto, Indoor, Outdoor, One Push, Auto Tracking, Manual
    • Backlight Compensation: Support
    • Digital Noise Reduction: 2D & 3D Digital noise reduction
    • S/N Ratio: 50dB

      Pan/Tilt
    • Pan Angle: 355°
    • Tilt Angle: -30° - +90°
    • Pan Speed: 1° - 80°/s
    • Tilt Speed: 1° - 60°/s
    • Preset Positions: 9x preset positions by IR remote controller, 255x preset positions by joystick controller or PC
    • Preset Accuracy: 0.1° ±10%
    • Flip: Support
    • Image Freeze: Support
    • PoE: 802.3af (Optional)

      AI
    • Humanoid Tracking: Supported
    • Auto Framing: Supported

      USB
    • Protocol: UVC 1.1
    • Operating System: Windows 7 and above, MacOS, Linux, Android
    • Video Compression: YUY2, MJPEG
    • Resolution: 1920x1080, 1280x720, 960x540, 800x600, 720x576, 720x480, 640x480, 640x360, 352x288, 320x240
    • Frame Rate: Max. 60
    • UVC Control: Support

      LAN
    • Protocol: TCP/IP, HTTP, RTSP, RTMP, RTMPS, SRT, ONVIF, DHCP, VISCA Over IP, NDIrHX2
    • Video Compression: H.264, H.265
    • Code Stream: Main code stream, Sub code stream
    • Main Stream Resolution: 1920x1080, 1280x960, 1280x720, 720x576, 720x480, 640x480
    • Sub Stream Resolution: 640x480, 640x360, 480x360, 352x288, 320x240, 176x144
    • Bitrate Control: VBR, CBR

      Audio and Interface
    • Audio Compression: AAC
    • Audio Bit Rate: 128kbps
    • HDMI Interface: HDMI 1.4
    • SDI Interface: 3G-SDI
    • USB Interface: USB 3.0, Type-B Socket
    • Network Interface: RJ45: 10M/100M adaptive Ethernet port
    • Audio Interface: Line In, 3.5mm jack
    • Serial Interface:
      - RS232 In/Out: 8-pin mini DIN, Up to 98.4ft (30m), VISCA/Pelco-D/Pelco-P Protocol
      - RS422/485: 5-pin Phoenix Interface, Up to 1200m, VISCA/Pelco-D/Pelco-P Protocol
    • Power Interface: JEITA RC-5320A Type 4

      Other
    • Tally Light: Support
    • Input Voltage: DC 12V
    • Input Current: Max. 1.5A
    • Power Consumption: Max. 18W
    • Color: Black
    • Dimension: 5.25" x 6.85" x 7.36" (134mm x 174mm x 187mm)
    • Weight: 2.65lbs (1.2kg)

  • Item Includes:

    • 1x IP Pro 30 PTZ Camera
    • 1x DC 12V Power Adapter
    • 1x IR Remote
    • 1x User Manual
    • 1x USB 3.0 Cable
    • 1x RS-232C Cable
    • 1x Ceiling Bracket

  • Warranty:

    • 1 Year Limited Warranty

  • GTIN:

    0601961419414
