QSC-AcousticDesign AD-DWL.180 5.25in 2-way Direct Weather Landscape Bollard Loudspeaker - 180 Degree Coverage - Green

ITEM #: QSC-AD-DWL-180 MFG #: AD-DWL-180

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

Our Price:

$660.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    AD-DWL-180 - Overview

    Perfect for almost any outdoor installation!

    The QSC AcousticDesign™ Series AD-DWL loudspeakers are weatherized and rugged, designed to face the elements while still offering a superior customized sound experience. Perfect for almost any outdoor installation they provide a lasting return on your loudspeaker investment.

    Optimal Outdoor Sound Experience
    Typical outdoor loudspeakers are inevitably placed in a myriad of locations, and when installed among obstructive landscaping or other recessed areas, the sound quality can suffer. The AcousticDesign™ Series Direct Weather landscape loudspeakers address this with an elevated bollard design, allowing sound to travel above obstructions for a more optimal listener experience while its unobtrusive green color (RAL 6020) and style allows it to blend with the environment. The available 180° model (AD-DWL.180) or 360° coverage model (AD-DWL.360) enables customization for your unique environmental requirements, and the companion subwoofer further elevates your sound profile.

    Impact Resistant
    With a lasting trend toward outdoor gatherings, landscape loudspeakers are exposed to more traffic than ever, from stray lawnmowers to party-going patrons. All AD-DWL models protect your investment by providing direct to concrete or in earth base supports for permanent installation, all with a common footprint to make installation easy.

    All Weather Durability
    Lower quality outdoor loudspeakers often fail when faced with constant weather-based challenges. Built to endure even the harshest marine environments, the AcousticDesign™ Series Direct Weather Series loudspeakers are built with durable polypropylene/fiberglass construction, stainless-steel hardware and feature an Ingress Protection (IP) Rating of IP55.

    • Features:

      • 180°directional coverage models; direct sound where you need it
      • Elevated bollard design allows sound to travel above obstructions
      • Permanent direct-to-concrete or in-earth base supports resist tampering
      • Green enclosures (RAL 6020) allow for unobtrusive aesthetic (or take advantage of paintable exterior finish)
      • Durable polypropylene/fiberglass construction and stainless-steel hardware; no fragile paper cone components
      • IP55 (Ingress Protection rating) and UL 1480 Compliant
      • Intrinsic CorrectionT advanced QSC voicing filter sets available via Q-SYS or CXD DSP amplifier platforms
      • Designed for a wide range of environmental conditions from -5 - 50C (20 - 125F),

    • Specifications:

      • Effective frequency range: 55 Hz - 25 kHz
      • Rated noise power: 80 W
      • Broadband sensitivity: >84 dB @1 W/1M (500 - 5 kHz)
      • Coverage angle (-6 dB): 180° (500 Hz - 5 kHz)
      • Directivity factor (Q): Coming Soon
      • Directivity Index: Coming Soon
      • Maximum continuous SPL: 104 dB
      • Maximum peak SPL: 110 dB
      • Rated impedance: 16 Ω
      • Transformer taps: 7.5 W, 15 W, 30 W, 60 W / 15 W, 30 W, 60 W
      • Transducer: (1) 5.25 in (135 mm) weather resistant cone woofer, ferrite magnet, rubber surround, (1) 1 in (25mm) aluminum dome tweeter, rubber surround
      • Input connector type: Wire pig-tail, blunt
      • Enclosure material: Glass-Filled polypropylene, F1-F2 UL Rated
      • Grille material: Polyester fabric on polycarbonate frame
      • Mount: Direct to concrete

        Enclosure Details
      • Ingress protection: (IP - 55)
      • Operating environment: Designed for outdoor use
      • Testing: Exceeded MilSpec819 standard for humidity, salt spray, temperature, and UV. Passed Mil-STD-202f standard for salt spray (specific to electrical components)
      • Product dimensions (HWD): 30.16 in x 6.46 in x 6.46 in (not including base support)
      • Net weight: 10.36 lb
      • Shipping weight: 14.8 lb
      • Shipping dimensions (HWD): 38.23 in x 10.63 in x 10.63 in

    • Item Includes:

      • 1x Direct-to-concrete mounting collar
