RCF HDL 10-A Active Line Array Loudspeaker

ITEM #: RCF-HDL10-A MFG #: HDL10-A

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$2,499.00

Our Price:

$2,099.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    HDL10-A - Overview

    The very compact size, no compromise transducers and a unique composite cabinet design make the RCF HDL 10-A the perfect tool in many situations. Ideal in live sound reinforcement and reliable installed situations. The HDL 10-A is the ideal choice when line array performance is needed and a fast and easy set up is a must. The system is powered from a 1400 Watt Peak Power 2 way digital amplifier, sound is processed from a powerful DSP. The HDL 15-AS is the ideal flyable bass complement for the HDL 10-A array system.

    The HDL 10-A is a true active and high power ready to use touring system equipped with a high efficiency digital amplifier that delivers superior SPL reducing energy requirement. The integrated processing and the cabling reduction will make the set-up faster and easier and, thanks to its compact size, the truck space requirement is reduced to the minimum.

    • Features:

      • 1400 Watt Peak power - 700 Watt RMS
      • 133 dB max SPL
      • 65 Hz 20 kHz frequency response
      • 2 x 8" Woofers
      • 1 x 2" Compression Driver
      • DSP controlled Input section with selectable presets
      • Tour grade safe and solid variable mechanics
      • Composite PP enclosure structurally wooden reinforced

    • Specifications:

      • Acoustical specifications
      • Frequency Response: 65 Hz ÷ 20000 Hz
      • MAX SPL @ 1M: 133 dB
      • Horizontal Coverage Angle: 100°
      • Vertical Coverage Angle: 15°

        Transducers
      • Compression Driver: 2.0", 2.5" v.c
      • Woofer: 2 x 8", 2.0" v.c

        Input/Output section
      • Input Signal: bal/unbal
      • Input Connectors: XLR
      • Output Connectors: XLR
      • Input Sensitivity: -2 dBu/+4 dBu

        Processor section
      • Crossover Frequencies: 800 Hz
      • Protections: Thermal, RMS
      • Limiter: Soft Limiter
      • Controls: Cluster, HF, High curving, Indoor

        Power section
      • Total Power: 1400 W Peak, 700 W RMS
      • High Frequencies: 400 W Peak, 200 W RMS
      • Low Frequencies: 1000 W Peak, 500 W RMS
      • Cooling: Convection
      • Connections: Powercon IN/OUT

        Standard compliance
      • CE Marking: Yes

        Physical specifications
      • Cabinet/Case Material: PP Composite
      • Hardware: Rigging flyware
      • Handles: 2 side
      • Grille: Steel
      • Color: Black

        Size
      • Height: 294 mm / 11.57"
      • Width: 569 mm / 22.4"
      • Depth: 434 mm / 17.09"
      • Weight: 20.4 kg / 44.97 lbs

        Shipping Information
      • Package Height: 375 mm / 14.76"
      • Package Width: 650 mm / 25.59"
      • Package Depth: 500 mm / 19.69"
      • Package Weight: 23 kg / 50.71 lbs

    • GTIN:

      8024530010850
