    M32 DA PRO II - Overview

    The RME M-32 DA Pro II (Part of the M-32 Pro II Series) is designed to meet the demanding requirements of professional studios, immersive sound installations, live sound systems, and industrial applications that need a reliable solution for analog conversion with high-end network audio processing. These new converters are available with either 32 analog inputs or outputs, and either with Dante® or AVB for a choice of four different models.

    Boasting up to 32-channels, fully equipped MADI I/Os (coaxial & optical via optional SPF module), improved specs with extremely low THD values, intelligent channel routing and innovative usability, the brand-new M-32 Pro II Series truly represents the state-of-the art in exceptional audio performance.

    • Features:

      • 32 x Analog In/Out (25-pin D-sub, up to +24 dBu)
      • 2 x MADI I/O (via optional available optical SFP and coaxial BNC, up to 128 Ch.)
      • 2 x RJ45 1 GigE AVB, four streams with 4/8/12/16 Ch. each
      • Word Clock I/O (BNC)
      • 2 x monitored fully redundant internal PSUs
      • 32-channel AD converter, fully symmetrical design, 120 dBa
      • 19" enclosure 1 unit height
      • Large, tri-color backlit channel indicators with Peak/RMS metering
      • Magnetic cover with customizable channel labels
      • SyncCheck® and ICC® - detects when a clock source is not in sync and falls back to other available signals
      • MADI Auto-Input - seamless redundancy
      • 2" display with control knob for full device control
      • 15 Preset storage, firmware upgrade persistent
      • Lock (optional code) and dark mode
      • Internal routing of up to 224x192 M-32 AD Pro / 192x224 M-32 DA Pro channels in 4 channel blocks (32 x Analog, 64 x MADI Opt, 64 x MADI Coax, and 64 x AVB)
      • Remote control via HTTP, JSON, IEEE 1722.1 AVDECC ] MIDI over MADI and optional MIDI


    • Specifications:

      • M-32 Pro DA II Line Out 1-32:
      • Resolution: 24 bit
      • Output level switchable per channel +24 dBu, +19 dBu, +13 dBu @ 0 dBFS
      • Outputs DC coupled, fully symmetrical signal path ("truly balanced")
      • Output impedance: 200 Ohm balanced, 100 Ohm unbalanced
      • Signal to Noise ratio (SNR) @ +13/+19/+24: 116 dB RMS unweighted, 119 dBA
      • Frequency response @ 44.1 kHz, -0.1 dB: 0 Hz - 22 kHz
      • THD @ -1 dBFS: < -109 dB, < 0.00035 %
      • THD+N @ -1 dBFS: < -107 dB, < 0.00043 %
      • Channel separation: > 110 dB
