RME M32 AD PRO II-D 32-Channel High-End 192 kHz DA Converter with Dante and MADI

ITEM #: RME-M32ADPRO-IID MFG #: M32 AD PRO II - D

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
RME Audio
Free Shipping with $49 Minimum Order

List Price:

$4,999.00

Our Price:

$4,599.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
    Report Lower PriceLarge Quantity Quote

    M32 AD PRO II - D - Overview

    The RME M-32 AD Pro II-D (Part of the M-32 Pro II Series) is designed to meet the demanding requirements of professional studios, immersive sound installations, live sound systems, and industrial applications that need a reliable solution for analog conversion with high-end network audio processing. These new converters are available with either 32 analog inputs or outputs, and either with Dante or AVB for a choice of four different models.

    Boasting up to 32-channels, fully equipped MADI I/Os (coaxial & optical via optional SPF module), improved specs with extremely low THD values, intelligent channel routing and innovative usability, the brand-new M-32 Pro II Series truly represents the state-of-the art in exceptional audio performance.

    • Features:

      • 32 x Analog In/Out (25-pin D-sub, up to +24 dBu)
      • 2 x MADI I/O (via optional available optical SFP and coaxial BNC, up to 128 Ch.)
      • 2 x RJ45 for Dante network connectivity (up to 64 channels)
      • (optional) MIDI I/O for legacy MIDI Remote
      • Word Clock I/O (BNC)
      • USB 2.0 (for remote control)
      • 2 x monitored fully redundant internal PSUs
      • 32-channel AD converter, fully symmetrical design, 120 dBa
      • 19" enclosure 1 unit height
      • Large, tri-color backlit channel indicators with Peak/RMS metering
      • Magnetic cover with customizable channel labels
      • SyncCheck® and ICC® - detects when a clock source is not in sync and falls back to other available signals
      • MADI Auto-Input - seamless redundancy
      • 2" display with control knob for full device control
      • 15 Preset storage, firmware upgrade persistent
      • Lock (optional code) and dark mode
      • Remote control via HTTP, JSON, MIDI over MADI and optional MIDI


    • Specifications:

      • M-32 Pro II-D AD Line In 1-32:
      • Resolution: 24 bit
      • Input level switchable per channel +24 dBu, +19 dBu, +13 dBu @ 0 dBFS
      • Inputs AC coupled, fully symmetrical signal path (servo-balanced)
      • Signal to Noise ratio (SNR) @ +24 dBu, 44.1 kHz: 117.0 dB RMS unweighted, 120.7 dBA
      • Signal to Noise ratio (SNR) @ +19 dBu: 116.3 dB RMS unweighted, 119.9 dBA
      • Signal to Noise ratio (SNR) @ +13 dBu: 114.7 dB RMS unweighted, 118.3 dBA
      • Frequency response @ 44.1 kHz, -0.1 dB: 5 Hz - 20.5 kHz
      • THD @ -1 dBFS: < -111 dB, < 0.00029%
      • THD+N @ -1 dBFS: < -108 dB, < 0.00039 %
      • Channel separation: > 110 dB
