Sony SRG-A40 30x Zoom 4K PTZ Camera with Auto Framing and AI Analytics - Black

ITEM #: SNY-SRGA40 MFG #: SRGA40

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$4,399.99

Our Price:

$3,105.88

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    SRGA40 - Overview

    Shooting redefined. AI makes you free!

    SRG-A40 with PTZ Auto Framing
    Revolutionary PTZ Auto Framing technology powered by built-in AI analytics ensures high-quality composed shots without an operator.
    Shooting redefined. AI makes you free.

    A Camera that Automatically and Naturally Shoots Video for you
    With the advanced PTZ Auto Framing feature, the camera automatically tracks the target in a comfortable viewing with smooth Pan-Tilt-Zoom movement, regardless of posture, movement and what one is wearing.
    Since the camera does most of the work automatically, the operator can spend their time efficiently.

    PTZ Auto Framing with built-in AI analytics
    This camera harnesses powerful AI-powered video analytics that can automatically detect and track the position of a presenter within the camera frame. As the presenter moves, the camera's pan/tilt/zoom mechanism ensures that the presenter is always framed naturally, without the need for a human camera operator to manually follow their movements.

    Automatically and reliably shoots video for you
    With Sony's newly developed AI analytics algorithm, it detects the subject's skeleton and head position and matches the subject's detail features even when there are several people in the frame. It achieves accurate framing and consistent tracking.

    • Features:

      • High Speed Pan/Tilt
      • Wide Angle Zoom Lens
      • PTZ Auto Framing
      • Preset Camera Positions
      • Picture Freeze Preset
      • AF, AE and AWB
      • PTZ Motion Sync
      • 4K30p IP Streaming
      • Single Network Cable with POE++
      • HDMI/SDI Outputs

    • Specifications:

      • Image Sensor: 1/2.5 type ExmorR CMOS
      • Image Sensor (Number of Effective Pixels): Approx. 8.5M pixels
      • Signal System:
        - 2160/29.97p, 25p, 23.98p
        - 1080/59.94p, 50p, 29.97p, 25p, 23.98p
        - 1080/59.94i, 50i
        - 720/59.94p, 50p
      • 4K capability: Yes
      • Minimum Illumination (50IRE): 1.6 lux (1/30s 50IRE F2 high-sensitivity OFF)
      • Horizontal Resolution:
        - 1700 TV lines (Center)(4K)
        - 1000 TV lines or higher (Center)(FHD)
      • Gain:
        - Auto/Manual (0 to +48 dB)
        - High Sensitivity On
      • Shutter Speed:
        - 1/1 to 1/10000 sec(59.94 Hz system)
        - 1/1 to 1/10000 sec(23.98 Hz system)
        - 1/1 to 1/10000 sec(50Hz system)
      • Exposure Control: Auto/Manual/Priority AE (Shutter, Iris)
      • White Balance: Auto1/Auto2/One Push WB/Indoor/Outdoor/Manual
      • Zoom Capability: 30x(4K with CIZ*), 40x (HD with CIZ), Max. 80x (HD with CIZ and Tele Convert Mode) *CIZ = Clear Image Zoom
      • Focusing System: Auto/Manual
      • Horizontal Viewing Angle: Approx. 70.0 degree (Wide)
      • Focal Length: f=4.4 mm (Wide) to 52.8 mm (Tele)
      • F-number: F2.0 to F3.7
      • Minimum Object Distance: 80 mm (Wide) - 400 mm (Tele)
      • Pan/Tilt Angle:
        - Pan: ±170°
        - Tilt: +90°/-20°
      • Pan/Tilt Speed (Max.):
        - Pan: 300 degrees/sec
        - Tilt: 126 degrees/sec
      • Pan/Tilt Speed:
        - Pan: 1.1° to 101°/s
        - Tilt: 1.1° to 91°/s
      • Pan/Tilt Speed(Slow):
        - Pan: 0.5° to 60°/s
        - Tilt: 0.5° to 60&dg;/s
      • Pan/Tilt Slow Mode: Yes
      • Pan/Tilt Operation Noise:
        - NC30 or less (*4)
        - (*4) Sony measurement conditions
      • Preset Position:
        - 256 (CGI)
        - 100 (VISCA)
      • Picture Freeze Preset: Yes
      • PTZ Motion Sync: Yes
      • Power Requirements:
        - DC 19.5V
        - PoE++(IEEE802.3bt type4 class8)
      • Power Consumption:
        - DC19.5V: 80W
        - PoE++: 71.3W
      • Operating Temperature: 0°C to 40°C (32°F to 104°: F)
      • Storage Temperature: -20°C to +60°C (-4 °F to +140°F)
      • Approximate Dimensions (W x H x D): 156.7 x 184.0 x 200.0 mm (6 1/4 x 7 1/4 x 7 7/8 inch)

    • Item Includes:

      • 1x AC power adapter
      • 1x IR Remote Commander Unit
      • 2x Ceiling bracket
      • 1x Wire rope
      • 9x Screw M3 x8
      • 1x Screw M2.6 x6 BLACK
      • 1x HDMI cable fixing plate
      • 1x Safety regulation
      • 1x Download site information
      • 1x Warranty

    • Warranty:

      • 5 Year Warranty

    • GTIN:

      0272429255716
