StarTech M2E1BMU31C M.2 NVMe SSD Enclosure for PCIe SSDs - USB 3.1 Gen 2 USB-C

M2E1BMU31C - Overview

• Features:

  • High Performance M.2 NVMe Storage: USB-C storage for your PCIe M.2 SSD. This enclosure features USB 3.1 Gen 2 (10Gbps) with UASP support & PCIe 3.0 for read/write data transfer speeds up to 1GB/s.
  • Durable & Portable: Aluminum housing protects the M.2 NGFF SSD and features ventilation holes for heat dissipation to ensure consistency at all performance levels. Ideal for data backup and recovery.
  • Broad Drive Compatibility: Compatible with M-Key PCI Express drives sized 2230/2242/2260/2280 including Samsung 950/960/970, Kingston, Seagate, Western Digital (WD), HP, and Intel SSD drives.


• Specifications:

  • Hardware
  • Bus Type: USB 3.1 Gen 2
  • Chipset ID: ASMedia - ASM2362
  • Compatible Drive Types: M.2 (PCIe, NVMe, M-Key, NGFF)
  • Drive Installation: Fixed
  • Drive Size: 22 mm - M.2 NVMe
  • Interface: USB 3.1 Gen 2
  • Number of Drives: 1
  • Supported Drive Height(s):
  • 2230
    2242
    2260
    2280

    Performance
  • 4Kn Support: Yes
  • General Specifications: Not compatible with M.2 SATA or AHCI based SSDs
  • Maximum Data Transfer Rate: 10 Gbps
  • MTBF: 233,398 Hours
  • TRIM Support: Yes
  • Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s
  • NVMe (PCIe Gen 3)
  • UASP Support: Yes

    Connector(S)
  • Host Connectors: 1 - M.2 (PCIe, M-Key, NVMe, NGFF)
  • 1 - USB 3.1 USB Type C (10 pin, Gen 2, 10 Gbps) Female

    Software
  • OS Compatibility: OS independent; No software or drivers required

    Indicators
  • LED Indicators: 1 - Power & Activity

    Power
  • Power Source: USB-Powered

    Environmental
  • Humidity:
  • Operation Humidity: 10 to 90% RH
    Storage Humidity: 5 to 95% RH
  • Operating Temperature: 0° to 40°C (32° to 104°F)
  • Storage Temperature: -10° to 65°C (14° to 149°F)

    Physical Characteristics
  • Color: Black
  • Material: Aluminum and Plastic
  • Height: 0.5" (1.3cm)
  • Length: 4.3" (10.8cm)
  • Width: 1.6" (40mm)
  • Weight: 2.3oz (65g)

    Packaging Information
  • Height: 1.4" (35mm)
  • Length: 6.1" (15.4cm)
  • Width: 4.2" (10.6cm)
  • Weight: 0.3Lbs (0.2kg)


• Item Includes:

  • 1x Drive Enclosure
  • 1x Set of M.2 Mounting Hardware (Installed)
  • 1x Screwdriver
  • 1x USB-C to USB-C Cable (50 cm)
  • 1x Quick-Start Guide


• Warranty:

  • 2 Years


• GTIN:

  0065030875691
