StarTech SV231DPU34K 2-Port DisplayPort KVM Switch - 4K 60Hz

ITEM #: ST-SV231DPU34K MFG #: SV231DPU34K

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

Our Price:

$388.99

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    SV231DPU34K - Overview

    The StarTech SV231DPU34K 2-port KVM switch combines 4K (60Hz) digital display capabilities with control of two connected computers.

    4K60 Picture and Full Audio Support
    The DisplayPort KVM switch supports resolutions up to 4K at 60Hz. It drives one large monitor at the full 4K resolution or, using an MST adapter, can drive various DisplayPort multi-display setups totaling 4K if you need to maximize viewing space. With support for digital audio (with supporting displays and sources) and separate 3.5 mm stereo audio, the DisplayPort 1.2 KVM switch delivers full audio compatibility.

    Integrated USB Hub
    The integrated USB 3.0 hub shares two peripherals (in addition to keyboard and mouse) among attached computers as if they were directly connected to your host computer, eliminating the cost of duplicate devices such as printers and scanners.

    Windows, Mac & Linux Compatible
    While supporting Windows, this DP KVM switch is also compatible with Mac and Linux operating systems.

    Easy to Operate
    The front-panel pushbuttons make it easy to switch between systems and activate the auto scan feature. The hotkey functionality makes accessing each system quickly, while a buzzer sound confirms the switch.

    Applications
    High-res medical imaging
    High-res digital signage server control
    Multimedia design and production

    StarTech offers a wide selection of high-quality KVM switches and KVM-related products to help you access your systems more efficiently without the expense and clutter of extra keyboards, mice, and monitors.This 2-port DisplayPort KVM switch is backed by a 2-year warranty and free lifetime technical support.

    • Features:

      • TAA compliant for government GSA schedule purchases
      • Increases productivity with ports to connect up to 2 HD multimedia computers
      • Achieves high picture quality with 4K resolutions @ 60Hz
      • Eliminates the need to purchase extra equipment with built-in 2-port USB 3.0 hub
      • Ensures full audio compatibility with digital and separate 3.5 mm audio support

    • Specifications:

      • Hardware
      • Audio: Yes
      • Cables Included: No
      • Daisy-Chain: No
      • Industry Standards: USB 3.0
      • DisplayPort 1.2
      • HDCP 2.2
      • KVM Ports: 2
      • Number of Monitors Supported: 1
      • PC Interface: USB 3.0
      • PC Video Type: DisplayPort

        Performance
      • Audio Specifications: 2-Channel Stereo
      • DVI Support: No
      • Hot-Key Selection: Yes
      • IP Control: No
      • Maximum Digital Resolutions: 3840x2160 @ 60Hz
      • Maximum Number of Users: 1
      • MTBF: 60000 hrs
      • On-Screen Display: No
      • Port Selection Support: Push Button and Hotkeys
      • Supported Resolutions: 1024x768; 1280x720 (High-definition 720p); 1920x1080 (High-definition 1080p); 1920x1200; 2560x1440; 2560x1600; 3840x2160 (Ultra HD 4K)

        Connector(s)
      • Console Interface(s): 4 - USB Type-A (4 pin; HID Port) USB 1.1 Female
      • 2 - USB Type-A (9 pin) USB 3.0 Female
      • 1 - DisplayPort Female Output
      • 1 - 3.5 mm Mini-Jack (3 Position) Female Output
      • Host Connectors: 2 - DisplayPort Female Output
      • 2 - 3.5 mm Mini-Jack (3 Position) Female Input
      • 2 - USB Type-B (9 pin) USB 3.0 Female

        LED Indicators
      • 2 - Green
      • 2 - Red

        Power
      • Center Tip Polarity: Positive
      • Input Current: 0.6A
      • Input Voltage: 100 ~ 240 AC
      • Output Current: 1.5A
      • Output Voltage: 12 DC
      • Plug Type: M
      • Power Consumption (In Watts): 18 W

        Physical Characteristics
      • Color: Black
      • Enclosure Type: Steel
      • Humidity: 0% - 80%
      • Operating Temperature: 0°C ~ 40°C
      • Storage Temperature: -10°C ~ 60°C
      • Product Height: 1.6 in [40 mm]
      • Product Length: 3.9 in [100 mm]
      • Product Weight: 22 oz [624 g]
      • Product Width: 6.3 in [160 mm]
      • Shipping (Package) Weight: 0.3 lb [0.2 kg]

    • Item Includes:

      • 1 - KVM Switch
      • 1 - Universal Power Adapter (NA/JP, EU, UK, ANZ)
      • 4 - Rubber Foot Pads
      • 1 - Quick-Start Guide

    • Warranty:

      • 2 Year

    • GTIN:

      0065030880121
