Tripp Lite B022-U08 NetDirector 8-Port 1U Rackmount KVM Switch
  • Tripp Lite B022-U08 NetDirector 8-Port 1U Rackmount KVM Switch
  • Tripp Lite B022-U08 NetDirector 8-Port 1U Rackmount KVM Switch
  • Tripp Lite B022-U08 NetDirector 8-Port 1U Rackmount KVM Switch

Questions? Ask a Markertek Expert:
800-522-2025 Email

Tripp Lite B022-U08 NetDirector 8-Port 1U Rackmount KVM Switch

Manufacturer: Tripp Lite

Item #: TRL-B022-U08   •   MFG #: B022-U08



List Price:$512.00
Our Price:$354.24

free ship


Availability: Usually ships in 3-10 business days
i
This item is currently out of stock and will ship the minute we receive it – typically 3-10 business days. Need it sooner? Expedited delivery options may be available. Email [email protected] or call customer service at 800-522-2025 and we'll make it happen.




    Share!

    California Residents:
    8pt-triangleWARNING:
    Cancer and Reproductive Harm - www.P65Warnings.ca.gov





    The B022-U08 NetDirector 8-Port 1U Rackmount KVM Switch allows IT professionals to control up to eight computers from one keyboard, mouse and monitor. The unit mounts into 1U of rack space and serves as either a stand-alone KVM switch or an expansion unit to other NetDirector KVM switches, such as Tripp Lite’s B020-U16-19-K. The B022-U08 is compatible with all major operating systems. Daisy-chain up to 31 additional units to control a maximum of 264 computers. When connected as part of a daisy-chain, each individual B022-U08’s position is sensed automatically without needing to manipulate DIP switch settings.

    The advanced on-screen display (OSD) is available in English, Spanish, French, German or Japanese and supports high-definition video up to 2048 x 1536. Compatible with both USB and PS/2 connections using the included cable kit, this KVM switch allows you to switch between connected computers using front-panel pushbuttons, the OSD or keyboard hotkey commands. And by connecting an optional Tripp Lite B051-000 Server Remote Control, you’ll be able to control all connected computers from anywhere via LAN, WAN or the Internet.

    Two levels of security allow you to delegate proper access to approved personnel up to four Users and one Administrator. A convenient auto-scan feature lets you monitor all connected computers without having to manually switch between them. A front USB 1.1 port lets you share flash drive or external hard drive data with the connected computers.


    • Features

      • Supports video resolutions up to 2048 x 1536
      • Daisy-chain up to 32 switches to control up to 264 computers
      • Front USB port enables external data sharing to all computers
      • Works with all major operating systems
      • Optional IP remote access with Tripp Lite B051-000
      • Control Up to 264 Computers or Servers
      • Advanced on-screen display (OSD) supports high-definition video up to 2048 x 1536
      • Compatible with USB and PS/2 keyboards and mice
      • Switch between computers via front-panel buttons, OSD or keyboard hotkeys
      • Auto-scan feature lets you monitor all connected computers without manually switching between them
      • Daisy-chain up to 32 units to control a maximum of 264
      • computers or servers
      • Position in daisy-chain sensed automatically without adjusting DIP switch settings Built-In Security Keeps Data Safe
      • 2 levels of security (4 Users and one Admin) allow you to delegate proper access
      • Included firmware upgrade cable keeps the software up to date Versatile to Meet Your Specific Needs
      • Compatible with all major operating systems
      • User-friendly OSD available in English, Spanish, French, German and Japanese
      • Front USB 1.1 port accepts USB peripherals, such as flash drives and external hard drives, for data sharing with all connected computers Optional IP Remote Access
      • Add Tripp Lite B051-000 Server Remote Control to operate all connected computers from anywhere via LAN, WAN or the Internet Rackmounted Convenience
      • Mounts into just 1U to save valuable rack space
      • Rugged steel housing and premium connectors built to last

    • Specifications

      • Users: 1
      • AC Adapter: Input: 100-240V, 50/60 Hz, 0.5A / Output: 5.3V, 2.4A
      • IP Remote Access: No
      • Ports: 8
      • PC/Server Connections: PS/2
      • Cat5 KVM Switch: No
      • Product Warranty Period (Worldwide): 1-year limited warranty; Not applicable

    • Item Includes

      • B022-U08 NetDirector 8-Port 1U Rackmount KVM Switch
      • USB/PS2 combo console cable kit
      • RJ45-to-DB9 firmware upgrade cable
      • AC power adapter (Input: 100–240V, 50/60 Hz, 0.5A; Output: 5.3V, 2.4A)
      • Grounding wire
      • Mounting hardware
      • Rubber feet
      • CD with owner's manual
      • Quick Start Guide

    • Warranty

      • 1 Year
