Community V2-8W Two-Way Loudspeaker 8 Inch 90 x 70 - White

ITEM #: CMTY-V2-8W MFG #: V2-8W

Primary Image
Free Shipping with $49 Minimum Order

Our Price:

$694.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    V2-8W - Overview

    The V2-8 is a two-way, full-range loudspeaker system suitable for use in a wide variety of fixed installations. Compact but powerful, it is ideal for distributed systems such as those found in caf‚s, restaurants, shopping centers and airports. When paired with a subwoofer such as the V2-210S, a V2-8 system will produce high-fidelity, broad spectrum sound that belies its modest size. The V2-8 is also an excellent choice for ancillary delay applications. When used to augment a front-of-house system in such venues as auditoria, theaters and houses of worship, delay loudspeakers can significantly even out the difference in sound pressure level from the front of the room to the rear of the room. Units may be positioned for underbalcony fill, overbalcony fill, or simply placed towards the rear of the seating areas. By deploying V2-8 loudspeakers in such a manner, the system designer will have far greater control over relative levels and relative tonal response when commissioning and equalizing the installation.

    The V2-8 may be mounted to a wall or ceiling surface using its included yoke bracket, suspended from its M6 threaded rigging points.

    • Features:

      • DYNA-TECHT driver protection circuitry.
      • Ferrofluid-treated HF driver for improved heat dissipation.
      • Carbon Ring Cone Technology provides 30% more piston area with increased excursion capability.
      • Constant-directivity rotatable square horn
      • Terminal strip and NL4-compatible connectors.
      • Available in standard black or white finishes.
      • Mounting yoke included with 10° and 20° vertical standoffs.
      • Optional V2-8T autoformer model for 70V/100V applications.

    • Specifications:

      • Loudspeaker Type: Compact two-way, full-range, trapezoidal, vented bass, user rotatable horn.
      • Frequency Response: 100 Hz to 16 kHz (±3 dB).
      • Max Input Ratings: 150W continuous, 375W program 34.6 volts RMS, 69.2 volts momentary peak.
      • Nominal Impedance: 8 ohms.
      • Minimum Impedance: 6.1 ohms @ 180 Hz.
      • Nominal -6dB Beamwidth: 90° H x 70° V (in vertical position).
      • Crossover Frequency: 1.3 kHz.
      • Recommended Signal Processing: 90 Hz, 24 dB/octave Butterworth high pass filter.
      • Drivers: LF 1 x 8-inch cone, HF 1 x 1-inch.
      • Input Connection: NL4-compatible locking connector with terminal strip in parallel.
      • Mounting/Rigging Provisions: 9 x M6 threaded rigging fittings, 4 x M6 threaded fittings for V-HSS and third-party suspension products.
      • Operating Range: 70 Hz - 18 kHz
      • Sensitivity (1W/1m): 92 dB
      • Power Handling: 150W continuous @ 8 ohms
      • Continuous Max Output: 114 dB (120 dB Peak)
      • Finish: Black or White catalyzed polyester painted 11-ply cross-laminated birch with powder-coated steel grille
      • Dimensions (H x W x D): 17.0" x 11.3" x 11.7" (433 x 287 x 298 mm)

    • GTIN:

      0617174016272
