    GPIO - Overview

    General purpose I/O interface for remote control
    Allen & Heath AH-DLIVE-GPIO is a general purpose IO switching interface for control integration of an AHM-64 matrix processor or dLive/Avantis mixing system and 3rd party hardware, offering 8 opto-isolated inputs and 8 normally open (N/O) relay outputs on Phoenix connectors in addition to 2x +10V DC outputs.

    The unit can be installed in a 19" rack (1RU / 1/2 width) or can be operated freestanding, and up to 8 GPIO modules can be connected to a dLive system - directly or via a 100Mb/s network switch - using Cat5 cable.

    GPIO functions are programmed using AHM System Manager or dLive Director software (PC or Mac), or via an Avantis mixer or dLive Surface, and can suit a number of applications including EVAC (alarm / system mute), broadcast (on air lights, fader start logic) and theatre automation (curtains, lights).

    • Features:

      • Up to 8 networked GPIO units can be added to a dLive/Avantis system
      • Networked Cat5 connection to Avantis mixer, dLive MixRack or Surface (<100m)
      • 8 opto-isolated inputs
      • 8 normally open (N/O) relay outputs, one of them configurable to Normally Closed output (N/C)
      • Industry standard Phoenix connectors
      • Freestanding or rack-mount (1RU / 1/2 Width) operation
      • PoE (IEEE 802.3af-2003) compliant
      • IO parameters configured via Avantis mixer, or dLive Surface or Director
      • 2 10V outputs (500mA max)


    • Specifications:

      • Relay Output Max Voltage: 24V
      • Relay Output Max Current: 400mA
      • Input: Switched to ground
      • External Power Output: +10VDC / 500mA max
      • Operating Temperature Range: 32°F to 95°F
      • Power Supply: 12V DC via external PSU (1A max) or PoE (IEEE 802.3af-2003) (0.9A max)
      • Dimensions: 6.75" x 8" x 1.7"
      • Weight: 2.7lbs
      • Boxed Dimensions: 6.75" x 8" x 1.7"
      • Boxed Weight: 6.6lbs


    • Item Includes:

      • 1x Allen & Heath AH-DLIVE-GPIO 1/2 Rack 8 GPI Opto-Isolated Contact Closures - 8 GPO Normally Open Relays - TCP/IP PoE Comp


    • GTIN:

      6938122246829
