Alfatron ALF-20X-SDIC 1080P HD PTZ Camera with SDI and a 20x Zoom Lens

ITEM #: ALF-20X-SDIC MFG #: ALF-20X-SDIC

  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
free ship

List Price:

$1,565.00

Our Price:

$1,489.99

Availability: Ships Factory Direct, Typically in 3-10 Days
iAvailability Description Popup


    ALF-20X-SDIC - Overview

    The Alfatron ALF-20X-SDIC is a 1080P HD PTZ camera with SDI connectivity and a 20x Zoom Lens, equipped for a high-quality video stream and high definition real-time synchronization. This PTZ camera is suitable for medium to large-sized meeting rooms, boardrooms, conference venues, and houses of worship.

    • Features:

      • 1080P HD PTZ Camera
      • 20X Optical Zoom
      • 2.07MP Sensor
      • Automatic focus, iris, shutter, white balance
      • Video over SDI, POE Ethernet, HDMI, & USB
      • Remote control via RS232, RS422
      • IR remote control

    • Specifications:

      • Optical Zoom: 20X, f5.5110mm
      • Sensor: 1/2.8-inch-high quality HD CMOS sensor
      • Effective Pixels: 16: 9,  2.07 megapixel
      • HDMI/SDI Video Format:
        1080P60/50/30/25/59.94/29.97
        1080I60/50/59.94
        720P60/50/30/25/59.94/29.97
      • CVBS output: 570i 480i
      • USB3.0 interface video format: [email protected] Max
      • USB2.0 interface video format: [email protected] Max
      • View Angle: 3.3°tele, 54.7°wide
      • AV: F1.6 – F3.5
      • Digital Zoom: 10X
      • Minimum Illumination: 0.5Lux (F1.8, AGC ON)
      • DNR: 2D & 3D DNR
      • White Balance: Auto / Manual/ One Push/ 3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K
      • Focus/Aperture/Electronic Shutter: Auto/Manual/One Push Focus
      • Iris: Auto/Manual
      • Shutter: Auto/Manual
      • BLC: ON/OFF
      • WDR: OFF/ Dynamic level adjustment
      • Video Adjustment: Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
      • SNR: >55dB
      • Video Output: HDMI, SDI, LAN, USB3.0, USB2.0
      • Video Stream: Dual stream output
      • Video Compression Format: LAN Interface: H.265, H.264, Dual stream output
      • USB2.0 Interface: H.265, H.264, MJPEG
      • USB3.0 Interface: YUV
      • Audio Input Interface: Double track 3.5mm linear input
      • Audio Output Interface: HDMI, SDI, LAN
      • Audio Compression Format: AAC/MP3/G.711A
      • Network Protocol: RTSP, RTMP, ONVIF, GB/T28181, Support network VISCA control protocol, Support remote upgrade, remote restart
      • Control Interface: RS232, RS485
      • Control Protocol: VISCA/Pelco-D/Pelco-P, Baud Rate: 115200/9600/4800/2400bps
      • Power Interface: HEC3800 outlet (DC12V)
      • Input Voltage: DC12V±10%
      • Input Electric Current: Maximum: 1A
      • Power Consumption: Maximum: 12W
      • Pan/Tilt Rotation: ±170°, -30°?+90°
      • Pan Control Speed: 0.1 -60°/sec
      • Tilt Control Speed: 0.1-30°/sec
      • Preset Speed: Pan: 60°/sec, Tilt: 30°/sec
      • Preset Number: 255 presets (10 presets by remote controller)
      • Stored Temperature: -10°C~+60°C
      • Storage Humidity: 20%~95%
      • Working Temperature: -10°C~+50°C
      • Working Humidity: 20%~80%
      • Dimensions: 178mm x 115.5mm x 150.9mm
      • Weight: 1.38KG

    • Item Includes:

      • 1x 12V/1.5A Power supply
      • 1x RS232 Control Cable
      • 1x USB Connection Cable
      • 1x Remote Control
      • 1x Manual
      • 1x Warranty Card
      • 1x Shelf Mount Bracket

    • Warranty:

      • 7 years

    • GTIN:

      0781159724848
