Alfatron ALF-C657D 6.5 Inch 30W Ceiling DANTE Master Speaker and Slave Speaker Pair With Built-In Amplifier

ITEM #: ALF-C657D MFG #: ALF-C657D

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$1,073.00

Our Price:

$999.99

Availability: Preorder
iAvailability Description Popup


ALF-C657D - Overview

The Alfatron ALFC-657D are 2x 30 watt full-range Dante ceiling speakers. It consists of a Dante Master speaker and a secondary Slave speaker. The Master speaker contains a 2 channel POE amplifier connected via the Dante audio network and provides an amplified speaker output for the slave speaker. As each pair of ALFC-657D speakers are powered via the network POE switch, it makes it a convenient choice for distributed sound reinforcement solutions.

  • Features:

    • Dante Master flush-mounted ceiling speaker with secondary Slave flush-mounted ceiling speaker
    • 2-Way full-range speaker design with coaxial HF transducer
    • 6.5" woofer with moisture/water-proof composite diaphragm
    • 1" silk dome tweeter with adjustable angle, producing rich mids, delicate highs and an overall warm sound.
    • 2x 30watt built-in 2-channel amplifier
    • Wide, flat frequency response and low distortion
    • POE powered
    • Flush-mounted ceiling installation
    • Metal back can
    • Weather resistant material for moisture and UV protection.
    • Border-less magnetic grille for easy installation and maintenance.

  • Specifications:

      Master Speaker
    • Frequency Response: 65Hz - 20kHz, (±3dB)
    • Impedance: 8Ω
    • Output SPL: 89dB 1M/1W
    • Output Max SPL: 111dB
    • RMS: 30 Watts
    • PAK: 60 Watts
    • Dante Power: 2x30 Watts
    • Transmission Speed: 100M/1000Mbps
    • Installation: Embedded/Hanging
    • Power Supply: RJ45, 802.3af/802.3at/802.3bt Compatible
    • Installation Depth:
      - 246mm Round hole
      - 197mm Depth
    • Bass: 6.5" (polypropylene) composite body and NBR rubber
    • Tweeter: 1" silk membrane, neodymium magnet, 360° rotatable
    • Audio Input Interface:
      - Input: RJ45
      - Output: Phoenix port (connect slave speaker-ALFC657-DS)
    • Cabinet: Iron grille and Iron engineering Material
    • Product Weight: 6.9lbs (3.15kg)
    • Accessory: Safety cable, Cut Out Template

      Slave Speaker
    • Frequency Response: 65Hz - 20kHz, (±3dB)
    • Impedance: 8Ω
    • Output SPL: 89dB
    • Output Max SPL: 111dB
    • RMS: 30 Watts
    • PAK: 60 Watts
    • Installation: Embedded/Hanging
    • Installation Depth:
      - 246mm Round hole
      - 197mm Depth
    • Bass: 6.5" (polypropylene) composite body and NBR rubber
    • Tweeter: 1" silk membrane, neodymium magnet, 360° rotatable
    • Audio Input Interface: Phoenix PIN port (Gets power from first Dante speaker)
    • Cabinet: Iron grille and Iron engineering Material
    • Product Weight: 6.3lbs (2.9kg)
    • Accessory: Safety cable, Cut Out Template

  • Item Includes:

    • 1x Dante Master Speaker (ALFC-657DM)
    • 1x Slave Speaker (ALFC-657DS)

  • Warranty:

    • 7 Year Limited Warranty

  • GTIN:

    0658325231137
