ADJ FOC615 Focus Wash 400 400W RGBACL LED Moving Head Wash Light Fixture with 10 to 41 Degree Zoom - IP20 Rated

ITEM #: AMDJ-FOC615 MFG #: FOC615

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$2,799.95

Our Price:

$1,999.99

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


FOC615 - Overview

The ADJ Lighting FOC615 FOCUS WASH 400 is a 400W moving head wash fixture powered by a 400W RGBALC Red, Green, Blue, Amber, Cyan and Lime) LED engine. A 6-inch Fresnel lens with 10 to 41 degree motorized zoom produces an even field light output.

Ideal for live broadcasting and film use, this fixture has flicker free operation, adjustable refresh rates from 900Hz to 25kHz, a quiet fan mode, linear white color temperature control from 2700K - 6500K, as well as, preset white color macros (2700K, 3200K, 4000K, 5600K and 6500K). In addition to it's tunable white feature, the Focus Wash 400 has a virtual CMY color mixing channel which allows users to choose any hue on a color picker.

The FOCUS WASH 400's unique color engine produces a high CRI of 90+ for bright whites and a CRI R9 of 88 to help make red tones more vibrant. The fixture also includes, 16-bit pan / tilt movement, RGBACL color mixing LED engine, variable dimming modes / curves and strobe effects, DMX and RDM (remote device management) protocol support.

The fixture comes standard with locking power In/Out connections, locking 3-pin & 5-pin DMX In/Out sockets, color LCD menu display with 6 button control panel, multiple unit power linking, a multi-voltage universal auto switching power supply (AC100-240V), USB port to conveniently update firmware, and omega brackets with two hanging points.

  • Features:

    • IP20 Rated
    • 7139 Total Stable Lumen Output
    • 50000 Hour Average LED Life

  • Specifications:

      Source
    • 400W 6-IN-1 LED (Red, Green, Blue, Amber, Cyan and Lime)
    • 50,000 Hour Average LED Life

      Photmetric Data
    • 7139 Total Stable Lumen Output (Full ON, Zoomed Out to Full)
    • 11072 LUX, 1029 FC @ 9.8' (3m) (Zoomed In/Full ON)
    • 1858 LUX, 173 FC @ 9.8' (3m) (Zoom Out/Full ON)
    • Beam Angle: 9.1° - 42.9°
    • Max Field Angle: 54.5°
    • Color Temperature: Tunable, 2400K - 8500K
    • CRI: 95.2

      Effects:
    • RGBACL Color Mixing
    • Virtual CMY Color Mixing
    • 9° - 42° degree Motorized Zoom
    • Electronic Strobe and Dimmer
    • Color Temperature Red to Green control via DMX
    • Linear Color Temperature control, 2700K to 10,000K
    • Preset Color Temperatures (2700K, 3200K, 4000K, 5600K and 6500K)

      Color
    • Individual RGBACL Red, Green, Blue, Amber, Cyan and Lime) Control
    • Virtual Color Wheel Control
    • Virtual CMY Control

      Control/Connections
    • 5x DMX Channel Modes: [Basic (17), Standard (22), Extended (24), CMY Standard (18) or CMY Extended (24)]
    • Selectable LED Refresh Rates, 900Hz to 25kHz.
    • Linear Dimming with user selectable Dim Curves, Dim Modes and Dim Speeds
    • 6-button Control Panel and LCD Menu Display
    • USB Firmware Update Port
    • RDM (Remote Device Management)
    • Quiet Fan Mode
    • Locking 3-pin and 5-pin XLR Connector In/Out
    • IP65 Locking Power Connector In/Out
    • With Wired Digital Communication Network

      Electrical/Thermal
    • Multi-Voltage: AC 100V - 240V, 47/63Hz
    • 460W Power Consumption @ 120V
    • 430W Power Consumption @ 240V
    • Multiple Unit Power Linking
    • 5°F - 113°F (-15°C - 45°C)

      Size/Weight
    • Length: 10.96" (278.43mm)
    • Width: 8.4" (213.33mm)
    • Vertical Height: (Without Snoot) 19.6" (498.1mm)
    • Vertical Height (With Snoot) 22.37" (568.1mm)
    • Weight: 23.5lbs (10.7kg)

      Approvals/Ratings
    • CE Compliant
    • cETLus (Control #4010765)
    • IP20

  • Item Includes:

    • 1x FOC615 Moving Head Light Fixture
    • 1x Snoot
    • 1x 40 Degree Linear Lens
    • 2x Omega Brackets
    • 1x Safety Cable
    • 1x IP65 Locking Power Cable

  • Warranty:

    • 2 Year Warranty

  • GTIN:

    0818651029130
