ARRI L0.0012956 SkyPanel S120-C Color Standard Diffusion Light Panel with Edison powerCON - Blue/Silver - Manual

ITEM #: ARR-L00012956 MFG #: L0.0012956

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$6,540.00

Availability: Extended Lead Time. Email, Chat or Call Us for more details.
iAvailability Description Popup
  • Shipment of this item is subject to a separate oversized-package carrier surcharge.


L0.0012956 - Overview

The Arri SkyPanel S120-C (L0.0012956) is twice as long as the S60, but weighs nearly the same. Its larger light aperture makes a great soft light even better. Retaining the same features and color tuneability as its smaller counterparts, the S120 consumes less than 400 watts, yet it is slightly brighter than the S60-C and has an outstanding efficacy of 90 lumens per watt.

A large surface area is a crucial feature of a good soft light. With an aperture of 1290 mm x 300 mm (50.8" x 11.8"), the S120 outputs a beautifully soft, even beam of light that has a wide range of uses. The long aspect ratio wraps light around objects and is perfect for vertical lighting of people. In addition the S120 works well as an overhead light for large areas, with the increased dimensions meaning that fewer lights and less cables are required.

SkyPanel is a compact, ultra-bright and high-quality LED soft light that sets a new standard for the industry. With a design focused on form, color, beam field and output, SkyPanel represents the culmination of more than a decade of research and development of LED technology at ARRI.

Incorporating features of ARRI’s successful L-Series LED Fresnels, SkyPanel is one of the most versatile soft lights on the market, as well as one of the brightest. Like the L-Series, SkyPanel ‘C’ (Color) versions are fully tuneable; correlated color temperature is adjustable between 2,800 K and 10,000 K, with excellent color rendition over the entire range. Full plus and minus green correction can be achieved with the simple turn of a knob, and in addition to CCT control, vivid color selection and saturation adjustment is also possible. The remote phosphor versions of SkyPanel are roughly 10% brighter than the color versions and have a lower price point.

Made in Germany to the high standards for which all ARRI products are known, SkyPanel is built to last - constructed from resilient materials and assembled by hand with great care. Other features include an on-board battery input for mobile applications, LAN port for network connectivity, USB-A port for firmware updates via thumb drive, and many more.

The state-of-the-art light engines and electronics built into every SkyPanel have paved the way for a powerful new feature in SkyPanel Firmware 3.0: lighting effects. With SkyPanel Lighting Effects users can now choose and manipulate 12 effects without the need for a lighting console or hours of programming. Each effect has several parameters that allow for customization of the effect to fit your needs. The lighting effects include: candle, clouds passing, club lights, color chase, cop car, fire, fireworks, light strobe, lightning, paparazzi, pulsing, and television. SkyPanel Lighting Effects changes the game for on-set lighting effect generation.

  • Features:

    • 90 Lumens per watt
    • Fully Tuneable - between 2,800 K and 10,000 K - Get the color you want in seconds.
    • Tremendous Output. One of the brightest soft lights on the market.
    • True Soft Light Beam Quality. Soft and uniform is the name of the game.
    • Outstanding Color Rendition.
    • LED white light without sacrifices.
    • A Single Soft, Clean Shadow. The proof is in the shadows.
    • Interchangeable Front Diffusor Panels
    • Operate on Location with On-Board Battery Input
    • Largest Light Aperture in its Power Class
    • Thin 5.1" Profile fits into Tight Locations

  • Specifications:

    • Lamphead: S120-C
    • Optical System: Soft Diffusion Panel
    • Light Aperture: 50.8 x 11.8 inches
    • Beam Angle: 110° (Half Peak Angle)
    • Weight: Manual Version: 35.3 lbs
    • Center Mount: 30.9 lbs
    • Pole Op Version: 43.2 lbs
    • Handling: Aluminum Yoke, High Strength Tilt Lock, Pole Operation Option (Pan & Tilt)
    • Mounting: 28 mm Spigot (Junior Pin)
    • Tilt Angle: +/- 90°
    • Lamphead Voltage Input: 48 V
    • Power Consumption: 400 W Nominal, 430 W Maximum
    • Lamphead Power Connection: Male 3-Pin XLR to 15 amp (Pin 1: Negative / Pin 2: Positive)
    • Battery Connector: Male 4-Pin XLR to 10 Amp (Pin 1: Negative / Pin 4: Positive)
    • Battery DC Voltage Range: 23 - 36 V
    • Battery Mode Light Output: 50% of Total Output
    • White Light: 2,800K to 10,000 K continuously variable Correlated Color Temperature
    • Colored Light: Full RBG+W color gamut with Hue and Saturation control
    • Color Temperature Tolerance: +/- 100 K (nominal), +/- 1/8 Green-Magenta (nominal)
    • Color Rendition: CRI Average > 95
    • Color Rendition: TLCI Average > 90
    • Green-Magenta Adjustment: continuously adjustable (Full Minusgreen to Full Plusgreen)
    • Dimming: 0 - 100% continuous
    • Control: On-Board Controller, 5-Pin DMX In and Through, EtherCon LAN network connectivity, USB-A, Art-Net
    • Remote Device Management (RDM*): *RDM Available in Future Firmware: DMX Setup, Hour Counter and Standard RDM commands
    • Software Interface: Ethernet: DMX Setup, Fixture Status and Firmware Upgrade through PC, Mac
    • USB-A: Software Upgrade via flash drive
    • Housing Color: Blue/Silver, Black
    • Ambient Temperature Operation: -4 to +113° F
    • Protection Class: IP 20
    • Estimated LED Lifetime (L70): 50,000 hours
    • Estimated Color Shift Over Lifetime: +/- 5%
    • Certifications: CE, CB, ENEC, cNRTLus, FCC, PSE
    • Power Supply Unit: S60/S120 PSU
    • Power Supply Input Range: 110 to 240 V ~, 50/60 Hz
    • Power Supply Output Range: 48 V
    • Power Input Connection: powerCON TRUE1 (Bare Ends / Schuko / Edison cables available)
    • Power Output Connection: Female 3-Pin XLR to 10 Amp (Pin 1: Negative / Pin 2: Positive) powerCON TRUE1 (mains power through)
    • Weight: 7.7 lbs.
    • Dimension: 15 x 7.6 x 3.5 inch
    • Control: On-Board On/Off Switch
    • Mounting: Super Clamp Attachment / SkyPanel PSU Rail Mount
