Audio-Technica ATW-DT3202DF2 D50 Handheld TX Base with LI-320 Battery for D50 Digital UHF Wireless System

ITEM #: AT-ATWDT3202DF2 MFG #: ATW-DT3202DF2

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$522.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


ATW-DT3202DF2 - Overview

The Audio-Technica ATW-DT3202DF2 is a rugged, handheld transmitter for use with the D50 digital UHF wireless system. The transmitter accepts a wide variety of additional capsules, including A-T's legendary Artist Elite ATW-C4100 cardioid dynamic, ATW-C6100 hypercardioid dynamic, ATW-C3300 and ATW-C5400 cardioid condensers as well as the ATW-C710 cardioid condenser and ATW-C510 cardioid dynamic. External control buttons and an OLED status display make the transmitter easy to use, and a special SideTrack function allows switching between multiple outputs - providing discrete live communications with fellow performers or audio engineers.

The transmitter is powered by a custom-designed lithium-ion battery, providing best-in-class battery life. The battery can be charged in the transmitter, using the ATW-CHG6 two-bay charging station, or can be removed from the transmitter and charged separately in the ATW-CHGA6 battery charger (ATW-CHG6 and ATW-CHGA6 sold separately).

  • Features:

    • Handheld transmitter for the D50 digital UHF wireless system
    • Compatible with a wide variety of additional capsules, including A-T's Artist Elite ATW-C4100, ATW-C6100, ATW-C3300, ATW-C5400, and ATW-C710, ATW-C510
    • Features external control buttons, programmable mute switch, OLED display, and a SideTrack function that enables switching between multiple outputs
    • Powered by a custom-designed lithium-ion battery for best-in-class battery life and convenient charging in the ATW-CHG6 two-bay charging station or ATW-CHGA6 battery charger (both sold separately)
    • Seven-color LED, along with seven physical color rings, make it easy to color code each channel
    • IR sync functionality enables easy synchronization with receiver
    • Best-in-class, all-metal construction

  • Specifications:

    • RF Output Power:
      - Standard: 20mW, 10mW, 1mW
      - HD Mode: 1mW
    • Microphone: Interchangeable microphone capsule-compatible
    • High-Pass Filter: 120Hz, 12dB/octave
    • Battery: Lithium-ion battery LI-320 (included)
    • Battery Life: 17.5 hours (10mW), may vary depending on usage conditions.
    • Operating Temperature Range: 23°F - 113°F (-5°C - 45°C)
    • Storage Temperature Range: -4°F - 131°F (-20°C - 55°C)
    • Dimensions (LxWxH): 13.86" x 4.92" x 2.68" (352mm x 125mm x 68mm)
    • Weight: 1.31lbs (0.59kg)

  • Item Includes:

    • 1x ATW-DT3202 handheld transmitter base
    • 1x Mic clamp
    • 1x Stand adapter
    • 1x ATW-RR1 removable anti-rolling ring
    • 1x LI-320 rechargeable lithium-ion battery
    • 1x ATW-TI20 color ring indicator kit
    • 1x Handheld transmitter storage pouch

  • Warranty:

    • 1 Year Limited Warranty
