Belden 10GX24 Multi-Conductor - Enhanced Category 6A Nonbonded-Pair Cable - Purple - 1000 Foot

ITEM #: BL-10GX24PE1000 MFG #: 10GX24 0071000

Primary Image

This item is no longer available.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the BL-10GX24PE1000

10GX24 0071000 - Overview

The Belden 10GX24 CAT6A 625Mhz 4 Pair U/UTP unishielded, zero Halogen, premise horizontal cable. With 23 AWG solid bare copper conductors, polyolefin insulation, patented Double-H spline, ripcord, and LSZH jacket.

  • Specifications:

    • Conductor Count: 8
    • Total Number of Pairs: 4
    • Conductor Size: 23 AWG

      Temperature Range
    • Installation Temp Range: +5°C To +50°C
    • Non-UL Temp Rating: +75°C
    • Storage Temp Range: -20°C To +75°C
    • Operating Temp Range: -20°C To +75°C

      Mechanical Characteristics
    • Bulk Cable Weight: 35 lbs/1000ft
    • Max Recommended Pulling Tension: 25 lbs
    • Min Bend Radius/Minor Axis: 1.25 in
    • Min Bend Radius/Installation: 3.0 in


  • GTIN:

    0612825061830
