Belden 8453 18 AWG 3 Conductor SV Type EPDM Portable Cordage - 500 Foot

ITEM #: BL-8453-500 MFG #: 8453 010500

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Belden
Free Shipping with $49 Minimum Order

List Price:

$2,286.60

Our Price:

$1,972.00

Add to Wish ListLeasing Options
Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup
    Report Lower PriceLarge Quantity Quote

    8453 010500 - Overview

    Belden 8453 is a Portable Cordage cable with 3 Conductors 18AWG (41x34) Tinned Copper, EPDM Insulation, Rubber Outer Jacket, and UL Type SV. Suitable for Junior light-duty vacuum cord(300V), Other light-duty equipements applications.

    • Specifications:

      • Elements: 3
      • AWG: 18
      • Stranding: 41x34
      • Material: Tinned Copper
      • UL Voltage Rating: 300 V (SV)
      • UL Rating Temp: 60°C
      • Operating Temp: -40°C to +60°C
      • Installation Min. Bend Radius: 2.6 in
      • Max. Pull Tension: 62 lbs
      • Bulk Cable Weight: 42 lbs/1000ft
      • Environmental Suitability: Indoor (Not Riser or Plenum), Indoor
      • Flammability / Fire Resistance: FT2
      • NEC / UL Compliance: SV
      • AWM Compliance: SV
      • CEC / C(UL) Compliance: SV
      • European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE)


    • Item Includes:

      • 1x Belden 8453 18 AWG 3 Conductor SV Type EPDM Portable Cordage - 500 Foot


    • GTIN:

      0612825207825
