Blustream SW21AB-V3 2-Way 4K 18Gbps HDMI 2.0 Switch with Optical and Analog Audio Breakout / Auto-Switching

SW21AB-V3 - Overview

Designed to simplify source management in meeting rooms, classrooms and commercial AV or residential environments!

• Features:

  • Features 2x HDMI inputs which can be switched to single HDMI output
  • Supports full HDMI 2.0 specification 4K UHD video (4K 60Hz 4:4:4) with HDR
  • HDCP 2.2 compliant
  • Supports 3D signal display
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Auto or manual switching capabilities. Auto switching from TMDS or 5V HPD
  • Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
  • HDMI audio breakout to phoenix balanced / unbalanced analog audio and optical (S/PDIF) digital outputs concurrently
  • Control via RS-232, front panel, and IR
  • Advanced EDID management
  • Auto-standby mode


• Specifications:

  • Casing Dimensions (WxHxD): 9.21" x 0.91" x 3.70" (234mm x 23mm x 94mm)
  • Dimensions Including Connections (WxHxD): 9.21" x 1.26" x 3.90" (234mm x 32mm x 99mm)
  • Shipping Weight: 1.76lbs (0.8kg)
  • Operating Temperature: 32°F - 104°F (0°C - 40°C)
  • Storage Temperature: -4°F - 140°F (-20°C - 60°C)
  • Video Input Connectors: 2x HDMI Type A, female
  • Video Output Connectors: 1x HDMI Type A, female
  • Audio Output Connectors: 1x Optical (S/PDIF) & 1x 5-pin Phoenix analog audio
  • IR Input Ports: 1x 3.5mm stereo jack (5V)
  • Power Supply: 5V/1A DC, screw barrel


• Item Includes:

  • 1x SW21AB-V3
  • 1x REMSW41V3 (no battery)
  • 1x 5V/1A DC Power Supply
  • 1x IRR Receiver (5V)
  • 1x Quick Reference Card
